Technical Alarms and Events Alarms and Events
14 - 12 0070-00-0575-50 Panorama™ Operating Instructions
Arrhythmia Off The Arrhythmia Off event will be posted in the Events database if
the Arrhythmia option is disabled on a patient’s monitoring
equipment.
The Arrhythmia Off event cannot be deleted from the Event database.
ST On The ST On event will be posted in the Events database if the ST
option is enabled on a patient’s monitoring equipment.
The ST On event cannot be deleted from the Event database.
ST Off The ST Off event will be posted in the Events database if the ST
option is disabled on a patient’s monitoring equipment.
The ST Off event cannot be deleted from the Event database.
Learning The Learning event will be posted in the Events database and the
Patient Status line, when the Arrhythmia/ST algorithm begins a
learning phase.
Central User Marked
Event
The Central User Marked Event event will be posted in the
Events database if the user has marked an event at the Panorama
Central Station.
Bedside User Marked
Event
The Bedside User Marked Event event will be posted in the
Events database if the user has marked an event at the bedside
monitor.
Central Transfer The Central Transfer event will be posted in the Events database if
a central-to-central transfer has been successfully completed at the
Panorama Central Station.
Room Transfer The Room Transfer event will be posted in the Events database if a
room-to-room transfer has been successfully completed at the
Panorama Central Station.
HEART RATE TECHNICAL EVENTS
RA Lead Off The RA Lead Off event will be posted in the Events database if the
RA lead is not connected to the patient, ECG lead I is selected and a
3-wire lead set, 5-wire lead set or a 12 lead card is in use.
The RA Lead Off message will be shown in the Patient Status line in
white text.
LA Lead Off The LA Lead Off event will be posted in the Events database if the
LA lead is not connected to the patient, ECG lead I is selected and a
3-wire lead set, 5-wire lead set or a 12 lead card is in use.
The LA Lead Off message will be shown in the Patient Status line in
white text.
LL Lead Off The LL Lead Off event will be posted in the Events database if the LL
lead is not connected to the patient, ECG lead I is selected and a 3-
wire lead set, 5-wire lead set or a 12 lead card is in use.
The LL Lead Off message will be shown in the Patient Status line in
white text.
Lead Off The Lead Off event will be posted in the Events database if 2 or
more of the ECG leads are not connected to the patient and a 3-wire
lead set, 5-wire lead set or a 12 lead card is in use.
The Lead Off message will be shown in the Patient Status line in white
text.
V Lead Off The V Lead Off event will be posted in the Events database if a V
lead is not connected to the patient and a 5-wire lead set is in use.
The V Lead Off message will be shown in the Patient Status line in
white text.
Technical Events (Continued)
MESSAGE REASON
