Physiological Alarms and Events Alarms and Events
14 - 8 0070-00-0575-50 Panorama™ Operating Instructions
NIBP (Mean) High NIBP Mean Alarm
Low NIBP Mean Alarm
Bedside NIBP Mean Alarm
The Panorama Central Station activates an NIBP
Mean alarm when the current value is either
equal to or higher/lower than the set alarm
limits.
T1 (F/C) High Temperature 1 Alarm
Low Temperature 1 Alarm
Bedside Temperature 1
Alarm
The Panorama Central Station activates a
Temperature 1 alarm when the current value is
either equal to or higher/lower than the set
alarm limits.
T2 (F/C) High Temperature 2 Alarm
Low Temperature 2 Alarm
Bedside Temperature 2
Alarm
The Panorama Central Station activates a
Temperature 2 alarm when the current value is
either equal to or higher/lower than the set
alarm limits.
ST Single ST Single Alarm
Bedside ST Single Alarm
The Panorama Central Station activates an ST
Single alarm when the current value of one ST
lead is either equal to or higher/lower than the
set alarm limits.
A separate ST Single alarm will be shown for
each lead of ST that independently violates the
alarm.
ST Dual ST Dual Alarm
Bedside ST Dual Alarm
The Panorama Central Station activates an ST
Dual alarm when the current value for two or
more ST leads are either equal to or higher/
lower than the set alarm limits.
A separate ST Dual alarm will be shown for
every two leads of ST that independently violate
the alarm.
Apnea Delay Apnea Alarm The Panorama Central Station activates an
Apnea alarm when the Apneic episode is either
equal to or longer than the set alarm limit.
PARAMETER
PANORAMA CENTRAL
STATION MESSAGES REASON
