14.1.2 Bedside Alarms
Alarms that are set at the bedside may be displayed and tracked at the Panorama Central
Station. Bedside alarm limit adjustments must be entered at the bedside monitor.
The Panorama Central Station only displays Bedside alarms if the Bedside Alarm
Tracking option has been disabled at the Panorama Central Station. For additional
information regarding Bedside Alarm Tracking, refer to ‘‘System Alarms (Alarm Limits) Tab’’
on page 9-14.
• End Tidal O
2
(ET O
2
)
•Inspired O
2
(INSP O
2
)
• End Tidal N
2
O (ET N
2
O)
•Inspired N
2
O (INSP N
2
O)
• End Tidal ISO (ET ISO)
• Inspired ISO (INSP ISO)
• End Tidal ENF (ET ENF)
• Inspired ENF (INSP ENF)
• End Tidal DES (ET DES)
• Inspired DES (INSP DES)
• End Tidal SEV (ET SEV)
• Inspired SEV (INSP SEV)
• End Tidal HAL (ET HAL)
• Inspired HAL (INSP HAL)
NOTE: The bedside alarms listed above can be set to an Alarm
Priority of 2 or 3. The factory default value is 3.
14.1.3 Physiological Alarm Event Messages
This section lists alarm messages that may appear at the Panorama Central Station.
PARAMETER
PANORAMA CENTRAL
STATION MESSAGES REASON
Heart Rate (HR) High Heart Rate Alarm
Low Heart Rate Alarm
Bedside Heart Rate Alarm
The Panorama Central Station activates a Heart
Rate alarm when the current value is either equal
to or higher/lower than the set alarm limits.
Respiration (ECG
Thoracic
Impedance, CO
2
and Gas Module)
High Respiration Rate
Alarm
Low Respiration Rate
Alarm
Bedside Respiration Rate
Alarm
The Panorama Central Station activates a
Respiration alarm when the current value is
either equal to or higher/lower than the set
alarm limits.
SPO
2
(Masimo
SET® and
Nellcor®)
High SPO
2
Alarm
Low SPO
2
Alarm
Bedside SPO
2
Alarm
The Panorama Central Station activates an SPO
2
alarm when the current value is either equal to
or higher/lower than the set alarm limits.
IBPx (Sys) Labels
include: IBP1,
IBP2, IBP3, IBP4,
ART, UA, LV, PA,
CVP, ICP, LA, RA
High IBPx Systolic Alarm
Low IBPx Systolic Alarm
Bedside IBPx Systolic
Alarm
The Panorama Central Station activates an IBPx
Systolic alarm when the current value is either
equal to or higher/lower than the set alarm
limits.
