User's Manual
Panorama™ Operating Instructions 0070-00-0575-50 14 - 3
Alarms and Events Physiological Alarms and Events
ALARM ALARM PRIORITY ALARM LIMIT NEONATE PEDIATRIC ADULT DEVICES
Heart Rate Units: bpm 1 or 2
Factory Default: 2
High Limit Off, 100-350
Factory Default: 200
Off, 100-300
Factory Default:180
Off, 60-250
Factory Default:150
Passport2
Spectrum
VPCS
Low Limit Off, 30-200
Factory Default: 100
Off, 30-150
Factory Default: 80
Off, 30-120
Factory Default: 50
Respiration
Units: rpm
2 or 3
Factory Default: 3
High Limit Off, 30-200
Factory Default: Off
Off, 15-150
Factory Default: Off
Off, 10-100
Factory Default: Off
Low Limit Off, 5-50
Factory Default: 5
Off, 5-40
Factory Default: Off
Off, 5-30
Factory Default: Off
SPO
2
Units: %
2 or 3
Factory Default: 3
High Limit Off, 80-100%
Factory Default: Off
Off, 80-100%
Factory Default: Off
Off, 80-100%
Factory Default: Off
Low Limit 50-99%
Factory Default: 92%
50-99%
Factory Default: 90%
50-99%
Factory Default: 85%
IBPx Sys.
Units: mmHg*
2 or 3
Factory Default: 3
High Limit Off, 5-180
Factory Default: Off
Off, 5-240
Factory Default: Off
Off, 5-300
Factory Default: Off
Low Limit Off, 0-130
Factory Default: Off
Off, 0-130
Factory Default: Off
Off, 0-150
Factory Default: Off
IBPx Dia.
Units: mmHg*
2 or 3
Factory Default: 3
High Limit Off, 0-70
Factory Default: Off
Off, 0-100
Factory Default: Off
Off, 0-140
Factory Default: Off
Low Limit Off, 0-50
Factory Default: Off
Off, 0-100
Factory Default: Off
Off, 0-120
Factory Default: Off
IBPx Mean
Units: mmHg*
2 or 3
Factory Default: 3
High Limit Off, 5-100
Factory Default: Off
Off, 5-100
Factory Default: Off
Off, 5-150
Factory Default: Off
Low Limit Off, 2-50
Factory Default: Off
Off, 2-50
Factory Default: Off
Off, 2-100
Factory Default: Off
All IBPx alarm limits apply to IBP1, IBP2, IBP3, IBP4, ART, UA, LV, PA, CVP, ICP, LA and RA.
The Panorama Central Station is capable of monitoring up to four IBP measurements.
Note: x = 1, 2, 3 or 4 when used with IBP
NIBP Sys.
Units: mmHg
2 or 3
Factory Default: 3
High Limit Off, 40-180
Factory Default: Off
Off, 40-180
Factory Default: Off
Off, 70-240
Factory Default: Off
Low Limit Off, 15-130
Factory Default: Off
Off, 15-130
Factory Default: Off
Off, 15-150
Factory Default: Off
N/A - Not Applicable
