1.2.5 Passport 2® Bedside Monitor
Passport 2 bedside monitors may be used to monitor patient data. The Passport 2 may use
either a hardwired or a wireless (2.4 GHz) configuration. The Passport 2
sends data to the
Panorama Central Station for analysis and storage via an Ethernet connection or remotely
via the Panorama Server. The type of data that can be collected by a Passport 2 is
dependent on the type of lead wire set and sensors used.
Parameters/Waveforms
PARAMETERS SETTINGS
PANORAMA
ALARMS
ECG/Heart Rate Waveform leads I, II, III are available with a 3-
wire lead set.
Low Heart Rate
High Heart Rate
Waveform leads I, II, III, aVR, aVL, aVF, V are
available with a 5-wire lead set.
Waveform leads I, II, III, aVR, aVL, aVF, V1, V2,
V3, V4, V5, V6 are available with a 12 lead card.
ST ST analysis is enabled ST Single
ST Dual
PVC/min. Arrhythmia analysis is enabled High PVC
V-Tach
V-Fib
Asystole
Bigeminy
Couplet
Irregular HR
Missed Beat
Run
Trigeminy
Triplet
V-Rhythm (12-lead)
Respiration (Source:
ECG, CO
2
and Gas
Module)
Respiration is enabled and ECG is the source.
CO
2
option is installed and CO
2
sensor is
attached.
Gas Module is installed and gas sensor is
attached.
Low Respiration
High Respiration
Apnea
SpO
2
SpO
2
sensor is attached. Low SpO
2
Rate
High SpO
2
Rate
IBP1/IBP2 (Systolic,
Diastolic, Mean)
IBPx option is installed and IBPx sensor is attached.
IBP parameter labels include IBP, Art, UA, LV, PA,
CVP, ICP, LA and RA. The label used is based on
the label selected at the bedside monitor.
Low IBPx Systolic
High IBPx Systolic
Low IBPx Diastolic
High IBPx Diastolic
Low IBPx Mean
High IBPx Mean
NOTE: x = 1, 2, 3 or 4
INSP/ET CO
2
CO
2
option is installed and CO
2
sensor is
attached.
Gas Module is installed and gas sensor is
attached.
High CO
2
Inspired
Low CO
2
End Tidal
High CO
2
End Tidal
INSP/ET O
2
Gas Module is installed and gas sensor is
attached.
O
2
Inspired
O
2
End Tidal
INSP/ET N
2
O Gas Module is installed and gas sensor is
attached.
N
2
O Inspired
N
2
O End Tidal
INSP/ET ISO Gas Module is installed, gas sensor is attached
and the Agent ID is ISO.
Agent ISO Inspired
Agent ISO End Tidal
