User's Manual

Messages and Issues Troubleshooting
12 - 26 0070-00-0575-50 Panorama™ Operating Instructions
12.1.34 Volume Tab
This section lists some of the potential messages and issues that may occur while using the
Volume tab.
12.1.35 Wave Gain Tab (Patient)
This section lists some of the potential messages and issues that may occur while using the
Patient Wave Gain tab.
12.1.36 Wave Gain Tab (System)
This section lists some of the potential messages and issues that may occur while using the
System Wave Gain tab.
MESSAGE/ISSUE * REASON SOLUTION
The System Setup menu
button is disabled.
The System Setup function is
already open on a Panorama
display and cannot be opened
on multiple displays.
Close the System Setup
function on the Panorama
display on which it is opened.
* Messages are shown in all bold text.
MESSAGE/ISSUE * REASON SOLUTION
No patient Selected! This message appears in the
demographic field when either
a patient tile has not been
selected or an empty tile was
selected.
Select an active patient tile.
The patient’s wave gain
settings did not change
The Done button was not
selected after the patient’s
wave gain settings were
changed.
Adjust the patient’s wave gain
settings and select the Done
button when the settings are
completed.
* Messages are shown in all bold text.
MESSAGE/ISSUE * REASON SOLUTION
The System Setup menu
button is disabled.
The System Setup function is
already open on a Panorama
display and cannot be opened
on multiple displays.
Close the System Setup
function on the Panorama
display on which it is opened.
* Messages are shown in all bold text.
