1.2.3 Panorama Telepack-2.4 and Panorama Telepack-608
The Panorama Telepack is a device that allows for the basic remote ECG monitoring of a
patient. A Panorama Telepack monitors Heart Rate, ST, PVC and Arrhythmia. The Telepack
sends data to the Panorama Central Station for analysis and storage via the Panorama
Telemetry Server. The type of data that can be collected by a Telepack is dependent on the
type of lead wire set and options configured for the connected patient.
NOTE: The Panorama Central Station is used to program,
configure, monitor and collect data for Panorama
Telepacks.
Additional Information
For additional information regarding Panorama Telepacks, refer to ‘‘Telepack (Optional)’’ on
page 10-1.
For information regarding how to program and configure an Panorama Telepack, refer to the
‘‘Wireless Tab’’ on page 9-46.
For information regarding the care and maintenance of an Panorama Telepack, refer to the
‘‘User Maintenance’’ on page 11-1.
For information regarding the parameters monitored by an Panorama Telepack, refer to
‘‘Parameter Specifications’’ on page 13-1.
Parameters/Waveforms
PARAMETERS SETTINGS
PANORAMA
ALARMS
ECG/Heart Rate Waveform leads I, II, III are available with a 3-wire
lead set (for Telepack-608 only).
Low Heart Rate
High Heart Rate
Waveform leads I, II, III, aVR, aVL, aVF, V are available
with a 5-wire lead set.
ST ST analysis is enabled ST Single
ST Dual
PVC/min. Arrhythmia analysis is enabled High PVC
V-Tach
V-Fib
Asystole
Bigeminy
Couplet
Irregular HR
Missed Beat
Run
Trigeminy
Triplet
