System Overview Supported Devices
The Panorama Central Station supports the following devices for use with the system:
• Panorama Central Station
• Panorama Telemetry Server
• Panorama Telepack-2.4 and Panorama Telepack-608
• Panorama Wireless Transceiver (Panorama Telepack-608 only)
•Network Printer
FIGURE 1-1 Panorama Patient Monitoring Network
Panorama
Central Station
(16 patient)
Panorama
Telemetry Server
Access Point (2.4 GHz)
Panorama Telepack - 2.4
Network Printer
Panorama Wireless Network
Optional
Passport 2
w/ Panorama Instrument
Radio - 2.4
Panorama Patient Network (E-LAN)
Panorama Central Network (C-LAN)
Panorama
Central Station
(16 patient)
Optional
Tuesday, April 18, 2000
2:40 PM
HUB
Switch
HUB
Passport 2
100BaseT
100BaseT
Spectrum
Panorama Wireless
Transceiver
Panorama Antenna
Passport 2
w/ Panorama Instrument
Radio -068
Panorama Telepack -
608
10Base T
PANORAMA PATIENT MONITORING NETWORK
