User's Manual

Wireless Tab System Setup Functions
9 - 54 0070-00-0575-50 Panorama™ Operating Instructions
Program Failure: Unable
to obtain a channel.
The system tried to obtain a
channel from the Panorama
Central Station but was
unsuccessful.
Select the OK button to close
the error message dialog box.
Free up any unused channels.
Try again to obtain a channel
from the system. The system
administrator can also
purchase additional channels.
Network Error: Unable to
obtain device list.
The system requested a device
list from the wireless network
but did not receive one within
the allocated request time.
Select the OK button to close
the error message dialog box.
Request a device list from the
wireless network again.
There are no devices
available
An empty device list was
received from the wireless
network.
Select the OK button to close
the error message dialog box.
Enter the device in the
Panorama Equipment list.
Free Error: Device not
found
The device channel was not
successfully freed.
Select the OK button to close
the error message dialog box.
Try to free a different channel
from the system. The system
administrator can also
purchase additional channels.
Program Failure: The
channel was successfully
freed but an error was
encountered when
programming the device.
The channel was successfully
freed but there was a problem
with the programming of the
device.
Select the OK button to close
the error message dialog box.
Program the device over its
existing channel.
MESSAGE/ISSUE * REASON SOLUTION
* Messages are shown in all bold text.
