User's Manual

Panorama™ Operating Instructions 0070-00-0575-50 9 - 53
System Setup Functions Wireless Tab
9.16.6.2 Free Connected Channel Sidebar Button
Select the Free Connected Channel sidebar button to free a channel from a connected
device that supports channels.
NOTE: The Free Connected Channel sidebar button will be disabled
until a valid device has been detected by the Panorama
Central Station.
NOTE: The Free Connected Channel sidebar button is reserved for
future use with WMTS wireless devices.
9.16.6.3 Normal Screen Sidebar Button
Select the Normal Screen sidebar button to return the display to the full screen mode, close
all tabs, message boxes and dialog boxes.
9.16.7 Troubleshooting
This section lists some of the potential messages and issues that may occur while using the
Wireless tab.
MESSAGE/ISSUE * REASON SOLUTION
The System Setup menu
button is disabled.
The System Setup function is
already open on a Panorama
display and cannot be opened
on multiple displays.
Close the System Setup
function on the Panorama
display on which it is opened.
You must enter all fields
to program the wireless
device
All of the fields in the
Wireless tab were not
completed before the
Program button was pressed.
Select the OK button to close
the error message dialog box.
Complete all of the fields in the
Wireless tab before selecting
the Program button.
Program Failure: Unable
to obtain a channel
A channel was not obtained
from the wireless network.
Select the OK button to close
the error message dialog box.
Obtain a channel from the
wireless network.
Program Failure: Invalid
Data
The wireless device was not
successfully programed.
Select the OK button to close
the error message dialog box.
Recheck the accuracy of the
data to be entered in the
wireless device.
Warning: Attached device
is already programmed
with a channel. Allocated
channel will be lost if not
freed first. Do you want
to continue
The connected device has
already been programmed and
allocated with a channel.
Select the OK button to close
the error message dialog box.
• Select the YES button to
discard the previously
allocated channel and try
to obtain a new channel.
• Select the NO button to
keep the previously
obtained channel.
* Messages are shown in all bold text.
