System Setup Functions Wireless Tab
9.16.6 Connect Field
The Connect field displays the status of the connection between the Panorama Central
Station and the wireless device. A connection status is shown in the Connect field when the
Wireless tab’s Read sidebar button is selected. The status in the Connect field cannot be
edited and has a factory default setting of blank.
The messages shown in the Connect field include:
List Box
The Error Log list box contains the error messages that occurred at the connected wireless
device. The following information is collected in an Error log:
• Filename column
The Filename column shows the names of the files in the error list.
• Line Number column
• The Line Number column shows the line numbers for the items in the error list.
• Message column
The Message column shows the messages that were sent to the Panorama system by the
Telepack device.
•Arg1 column
The Arg 1 column is populated by the text fields sent to the Panorama system by the
Telepack device.
•Arg2 column
The Arg 1 column is populated by the text fields sent to the Panorama system by the
Telepack device.
Error Log Read Sidebar Button
Select the Read sidebar button to retrieve error log messages from the connected wireless
device when it is connected to the Panorama Central Station in Service mode. A device is in
Service mode when it is connected to the Panorama Central Station’s serial port 2 via the
device’s programming cable.
Selecting the Read button will attempt to read the Error log from the connected wireless
device.
MESSAGE REASON
“Connected to 2.4 Telemetry” The connection with the Telepack 2.4 was
successful.
“Connected to 2.4 Instrument
Telemetry”
The connection with the 2.4 bedside monitor
was successful.
“Connected” The connection with the wireless device was not
successful.
“Error: Could not receive data” The connection with the wireless device was not
successful. Either there was no response from the
device or the device is not connected.
