System Setup Functions Wireless Tab
Device ID
The Device ID field displays the identification number that was assigned to the connected
wireless device. A Device ID has a maximum of 8 alphanumeric characters. Data is shown in
the Device ID field when the Wireless tab’s Read sidebar button is selected. If the read was
not successful the Device ID field will remain blank. To view the connection status of the
wireless device check the message in the Connect field. The Device ID field cannot be edited
and has a factory default setting of blank.
The Device ID for a monitoring device is set up in the Equipment List tab. For additional
information on setting up a Device ID, refer to the ‘‘Equipment Setup Tab’’ on page 9-21.
Connect Field
The Connect field displays the status of the connection between the Panorama Central
Station and the wireless device. A connection status is shown in the Connect field when the
Wireless tab’s Read sidebar button is selected. The status in the Connect field cannot be
edited and has a factory default setting of blank.
The messages shown in the Connect field include:
Software Version
The Software Version field displays the version of software currently in use by the wireless
device. Data is shown in the Software Version field when the Wireless tab’s Read sidebar
button is selected. The factory default setting is blank. If the read was not successful the
Software Version field will remain blank. To view the connection status of the wireless device
check the message in the Connect field.
Hardware Version
The Hardware Version field displays the version of hardware in use by the connected
device. Data is shown in the Hardware Version field when the Wireless tab’s Read sidebar
button is selected and has a factory default setting of blank. If the read was not successful the
Hardware Version field will remain blank. To view the connection status of the wireless
device check the message in the Connect field.
Telepack IP Address
The Telepack IP Address field displays the IP address for the connected wireless device. It
sets the IP address for the connected wireless device.
MESSAGE REASON
“Connected to 2.4 Telemetry” The connection with the Telepack 2.4 was
successful.
“Connected to 2.4 Instrument
Telemetry”
The connection with the 2.4 bedside monitor
was successful.
“Connected” The connection with the wireless device was not
successful.
“Error: Could not receive data” The connection with the wireless device was not
successful. Either there was no response from the
device or the device is not connected.
