User's Manual

Panorama™ Operating Instructions 0070-00-0575-50 9 - 45
System Setup Functions Wave Gain Tab (System)
2. Select the IBPX mmHg buttons until the desired IBPx wave gains is displayed. There
are four IBP buttons.
The settings available for the IBP wave gains include 0 - 20, 0 - 40, 0 - 80, 60 - 140, 0 -
160, 0 - 320 and (-10) - 10 mmHg. The factory default setting is 0 - 320 mmHg.
NOTE: If the IBP has been labeled at the bedside monitor it will
have the same label on its wave gain button.
3. Select the Resp Gain button until the desired Resp Gain wave gain is displayed.
The settings available for the Resp Gain wave gain include 1, 2, 3, 4 and 5. The factory
default setting is 1.
4. Select the CO2 (%, kPa, mmHG) button until the desired CO
2
wave gain is
displayed.
• The settings available for the CO
2
% wave gain include 5.0, 7.5 and 10.0 %. The
factory default setting is 10.0 %.
• The settings available for the CO
2
kPa wave gain include 5.0, 7.5 and 10.0 kPa. The
factory default setting is 10.0 kPa.
• The settings available for the CO
2
mmHg wave gain include 40, 60 and 100 mmHg.
The factory default setting is 100 mmHg.
5. Select the O2 % button until the desired O
2
wave gain is displayed.
The settings available for the O
2
wave gain include 18 - 30, 18 - 60 and 18 - 100 %.
The factory default setting is 18 - 100%.
6. Select the AGENT % button until the desired Agent wave gain is displayed.
The settings available for the agent wave gains include 0 - 1.0, 0 - 2.5, 0 - 5.0, 0 - 10.0,
0 - 15.0 and 0 - 20.0 %. The factory default setting is 0 - 20.0%.
9.15.3 Sidebar Button - Normal Screen
Select the Normal Screen sidebar button to return the display to the full screen mode, close
all tabs, message boxes and dialog boxes.
9.15.4 Troubleshooting
This section lists some of the potential messages and issues that may occur while using the
System Wave Gain tab.
MESSAGE/ISSUE * REASON SOLUTION
The System Setup menu
button is disabled.
The System Setup function is
already open on a Panorama
display and cannot be opened
on multiple displays.
Close the System Setup
function on the Panorama
display on which it is opened.
* Messages are shown in all bold text.
