1.1 Components of the Panorama System
The Panorama Patient Monitoring Network is a Medical Electrical System comprised of both
medical and non-medical devices (data processing equipment components). The system and
its components are marked in accordance with MDD, Annex IX classification criteria.
The configuration of the Panorama system may consist of any of the following components:
DESCRIPTION
MDD CLASSIFICATION
AND RULE COMMENT
18” Flat Panel
Touchscreen Display*
Class 1, Rule 12 CE marked by the vendor for compliance
with MDD and EMC Directives.
20” Touchscreen
Display*
Class 1, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
21” Touchscreen
Display*
Class 1, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
AP/Antennas Class I, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
Hub* Class 1, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
Passport 2® Patient
Monitor
Class IIb, Rule 10, dash 3,
“unless…” phrase
CE 0044 mark on the unit.
Spectrum™ Patient
Monitor
Class IIb, Rule 10, dash 3,
“unless…” phrase
CE 0044 mark on the unit and on individual
package.
Printer(s)* Class 1, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
Switch Class 1, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
UPS* Class 1, Rule 12 ITE equipment. CE marked by the vendor for
compliance with LVD and EMC Directives.
Panorama Central
Station Tower and
Server*
Class 1, Rule 12 ITE equipment. CE mark on the unit and
individual package.
Panorama Telepack-
2.4
Class IIb, Rule 10, dash 3,
“unless…” phrase
CE 0044 mark on the unit and on individual
package.
Panorama Telepack-
608
Class IIb, Rule 10, dash 3,
“unless…” phrase
CE 0044 mark on the unit and on individual
package.
Panorama Wireless
Transceiver
N/A N/A
Panorama Instrument
Radio
Class 1, Rule 12; ITE
equipment.
CE marked for compliance with LVD and
EMC Directives.
* Required components (only one of the 3 displays listed is required)
