2. Select the Delete button under the equipment list box.
NOTE: Only equipment not actively monitoring a patient can be
deleted.
3. The Are you sure you want to delete this device message dialog box is
displayed.
• Select the Yes button to delete the selected device and close the dialog box.
• Select the No button to keep the selected device and close the dialog box.
9.7.5 Sidebar Buttons
The following sidebar buttons are used to expand the functionality of this tab.
Print
Select the Print sidebar button to print the system Equipment List report.
To print the system’s Equipment List report, select the Print button. For information regarding
the specifications of the Equipment List report see the ‘‘Equipment Report’’ on page 8-31.
Normal Screen
Select the Normal Screen sidebar button to return the display to the full screen mode, close
all tabs, message boxes and dialog boxes.
9.7.6 Troubleshooting
This section lists some of the potential messages and issues that may occur while using the
Equipment tab.
MESSAGE/ISSUE * REASON SOLUTION
Equipment list is full This message appears when
the New button is pressed and
the equipment list contains the
maximum number of
equipment list entries.
Select the OK button to close
the dialog box. Delete a piece
of equipment from the
Equipment list.
Illegal Device Tile. Device
Tile must be defined.
Please try again.
This message appears when
the Done button is pressed in
the Equipment Setup tab
before a tile number is
selected.
Select the OK button to close
the dialog box. Select a tile
number in the Tile Number
dialog box.
The Tile button is disabled and
a dash (-) is shown in the Tile
field.
The type of equipment being
entered in the Equipment List is
either a Panorama Server or a
Panorama
You cannot enter a tile number
for the Panorama Server or the
Panorama equipment types.
Invalid Device Type This message appears when
the Done button is pressed in
the Equipment Setup tab
before a device type is
selected.
Select the OK button to close
the dialog box. Select a device
type in the Device Type dialog
box.
* Messages are shown in all bold text.
