User's Manual

Passwords Tab System Setup Functions
9 - 20 0070-00-0575-50 Panorama™ Operating Instructions
NOTE: Passwords are case sensitive.
5. Select the New Password text box. The keyboard dialog box displays.
6. Using the keyboard dialog box, enter the new alarm password. The Alarm password is
case sensitive and has a maximum 15 characters.
7. Accept the text entered in the keyboard dialog box. For additional information about
using the keyboard dialog box, refer to ‘‘Keyboard Dialog Box’’ on page 2-12.
8. Select the Confirm text box. The keyboard dialog box displays.
9. Using the keyboard dialog box, reenter the new alarm password. Accept or reject the
text entered in the keyboard dialog box. For additional information about using the
keyboard dialog box, refer to ‘‘Keyboard Dialog Box’’ on page 2-12.
The password is changed and the Passwords tab is returned to its original state.
Recording Password Changes
CAUTION: If passwords are changed from the factory defaults, users
MUST ensure that they document new passwords in the
space provided in this manual. For additional information
refer to ‘‘Passwords Tab’’ on page 9-19. Failure to recall
user defined passwords will render the system UNUSABLE.
NOTE: Restrict access among hospital staff to the System
password.
Record password changes in the following table:
9.6.3 Sidebar Button - Normal Screen
Select the Normal Screen sidebar button to return the display to the full screen mode, close
all tabs, message boxes and dialog boxes.
9.6.4 Troubleshooting
This section lists some of the potential messages and issues that may occur while using the
Passwords tab.
PROVIDES ACCESS TO DEFAULT PASSWORD USER PASSWORD
Patient Alarms alarm
* System Menus & System Shut
Down
system
MESSAGE/ISSUE * REASON SOLUTION
Incorrect password.
Please try again
The wrong password was
entered in the text box.
Select the OK button to close
the dialog box. Enter the
correct password in the dialog
box.
The System Setup menu
button is disabled.
The System Setup function is
already open on a Panorama
display and cannot be opened
on multiple displays.
Close the System Setup
function on the Panorama
display on which it is opened.
* Messages are shown in all bold text.
