• The time period format for Physiological Alarms will follow the system’s time format
• A volume level range of “Minimum - 10 Maximum”
• A factory default setting of 10
• Cannot be turned OFF
CAUTION: Do not block the speakers. Set the volume levels so that
alarms can be heard at all times, as described in this
Operation Manual.
1. Select the colored tile that corresponds to the time period for which the volume level is
being adjusted.
• A checkmark in the colored tile indicates that the tile has been selected and the
From/To fields are displayed.
• A colored tile without a checkmark indicates that the tile has not been selected.
2. Select the From/To fields to enter a time period for the selected physiological alarm.
The keypad dialog box displays.
• Delete existing hour and minute data by using the CLEAR or CE buttons on the
keypad.
• When using the 12-hour time format, the AM/PM toggle button switches between the
AM and PM settings.
NOTE: Time periods are mutually exclusive. When a new time
period is entered, the time periods for the other
physiological alarms are automatically adjusted to prevent
overlapping of time periods.
3. Set the desired volume level for the selected physiological alarm.
To adjust the volume level, either touch the arrows on the screen or use the mouse to drag
and drop the scroll bar to the desired level. The colored icon to the right of the scroll bar
is automatically moved when the volume level is adjusted.
4. Select the Done button to save the physiological alarm volume adjustments.
The Physiological Alarm volume adjustments will take effect upon pressing the Done
button.
9.4.3 Sidebar Button - Normal Screen
Select the Normal Screen sidebar button to return the display to the full screen mode, close
all tabs, message boxes and dialog boxes.
9.4.4 Troubleshooting
This section lists some of the potential messages and issues that may occur while using the
Volume tab.
MESSAGE/ISSUE * REASON SOLUTION
The System Setup menu
button is disabled.
The System Setup function is
already open on a Panorama
display and cannot be opened
on multiple displays.
Close the System Setup
function on the Panorama
display on which it is opened.
* Messages are shown in all bold text.
