9.3 Installation Setup Tab
The system Installation Setup tab (FIGURE 9-3) controls access to restricted Panorama
Central Station functions. The Installation Setup tab is a password protected tab.
This section includes the following:
• Accessing the Installation Setup Tab
•Entering a Password
• Sidebar Button - Normal Screen
• Troubleshooting
9.3.1 Accessing the Installation Setup Tab
1. From the menu bar, select the System Setup button. The first set of System Setup tabs
is displayed.
2. Select the Installation Setup tab.
FIGURE 9-3 Installation Setup Tab
9.3.2 Entering a Password
To gain access to the protected Panorama system functions, the correct password must be
entered in the Installation Setup tab’s password box. The password required for the
Installation Setup tab is defined in the system Password tab.
1. Select the Password field in the System Setup tab. The keyboard dialog box is
displayed.
2. Using the keyboard dialog box, enter the System password that was established in the
Passwords tab (maximum 15 characters). For security purposes asterisks (*) are
shown for each typed character.
3. Accept or reject the text entered in the keyboard dialog box. For additional information
about using the keyboard dialog box, refer to ‘‘Keyboard Dialog Box’’ on page 2-12.
The following tabs can be accessed after the correct password has been entered in the
Installation Setup tab: Volume, System Alarms, Passwords, Equipment Setup,
Date/Time, More/Previous, Print Setup, Recalibrate Touch Screen, Unit
Priorities, Unit Choices, Wave Gain and Wireless tabs.
