User's Manual

Alarm Limits Tab (Patient) Patient Alarm Functions
6 - 6 0070-00-0575-50 Panorama™ Operating Instructions
6.2.3 Sidebar Buttons
The following sidebar buttons are used to expand the functionality of this tab.
Restore Previous Settings
Select the Restore Previous Settings sidebar button to return patient display settings to
those in use when the tab was opened.
Suspend All Alarms (Optional)
Select the Suspend All Alarms sidebar button to suspend all numeric, lethal arrhythmia,
non-lethal arrhythmia and technical alarms at the Panorama Central Station for the selected
patient tile. The Suspend All Alarms sidebar button is only shown if the Suspend Level
1 option is ON in the System Alarms tab.
WARNING: The Panorama Central Station will not monitor any non-
lethal arrhythmia, numeric or technical alarms for the
selected patient tile when the Suspend All Non-lethal Alarms
button is enabled.
Select the Suspend All Alarms sidebar button to suspend a patient’s alarms at the
Panorama Central Station.
• When the Suspend All Alarms sidebar button is enabled, the button is white with
black text.
•The All Alarms Suspended message displays in red text in the Patient Status line of
the patient tile. For additional information regarding the Patient Status line, refer to the
‘‘Patient Status Line’’ on page 2-6.
To resume the monitoring of alarms, select the Suspend All Alarms sidebar button.
TABLE 6-1 Auto Set Percent Change
ALARM
PERCENT CHANGE
(APPROXIMATE)
Heart Rate 30%
Respiration 30%
IBP Systolic 20%
IBP Diastolic 20%
IBP Mean 20%
NIBP Systolic 20%
NIBP Diastolic 20%
NIBP Mean 20%
ET CO
2
(mmHg) 20%
INSP CO
2
(mmHg) 20%
ET CO
2
(%) 20%
INSP CO
2
(%) 20%
ET CO
2
(kPa) 20%
INSP CO
2
(kPa) 20%
Temp F° 3%
Temp C° 3%
