MimioProjector User Guide mimio.
© 2013 Sanford, L.P. All rights reserved. Revised 1/17/2013. No part of this document or the software may be reproduced or transmitted in any form or by any means or translated into another language without the prior written consent of Sanford, L.P. Mimio, MimioClassroom, MimioTeach, MimioCapture, MimioVote, MimioView, MimioHub, MimioBoard, MimioPad, MimioProjector, and MimioStudio are registered marks in the United States and other countries.
Contents About MimioProjector 7 What's Included 7 About MimioProjector 8 About the Control Panel 10 About the Remote Control 11 About the Connection Ports 13 Getting Started 15 Connecting the Projector 15 Connecting to a Computer 16 Connecting to a Video Source 17 Setting Up the Remote Control 18 Turning On the Power 19 Turning off the Power 20 Status Lights 21 Adjusting the Projected Image 22 Resizing the Projected Image 22 Focusing the Projected Image 22 Changing the Proj
Lamp Life Reminder 28 Lamp Power Mode 29 Clear Lamp Hours 29 Dynamic Black 29 High Altitude 29 Filters Remind 29 Information 30 Adjusting the Picture Color Mode 30 Wall Color 30 Brightness 30 Contrast 30 Sharpness 30 Saturation 31 Hue 31 Gamma 31 Color Temperature 31 Color Space 31 Adjusting the Screen 31 Aspect Ratio 31 Phase 32 Clock 32 Horizontal Position 32 Vertical Position 32 Digital Zoom 32 Vertical Keystone 32 Ceiling Mount 32 Adjusting the General
Volume 35 Microphone Volume 35 Caring for MimioProjector 37 Replacing the Remote Control Battery 37 Replacing the Lamp 38 Cleaning the Dust Filters 39 Getting Help 41 General Troubleshooting 41 Projector stops responding to all controls 41 Lamp burns out or makes a popping sound 41 Image Troubleshooting 41 No image is displayed 41 A partial, scrolling, or incorrect image is displayed 41 The notebook computer display is not displaying an image 42 Image is unstable or flickering 4
HDMI 1.
Chapter 1 About MimioProjector What's Included The MimioProjector package contains the following items: 1 3 2 CR2025 3V 4 5 1 Remote control 4 Power cord 2 Remote control battery 5 Projector with lens cap 3 VGA cable If you are missing any of the items above, contact Customer Support.
About MimioProjector About MimioProjector The following figure shows the major components of the MimioProjector.
About MimioProjector 1 Focus ring 6 Input/Output connection ports 2 Lens 7 Power connector 3 Control panel 8 Elevator feet 4 Lamp cover 9 Elevator feet spacers 5 IR Receiver 9
About MimioProjector About the Control Panel The following figure shows the components of the MimioProjector control panel. POWER TEMP LAMP 3 4 2 5 6 RESYNC SOURCE 7 1 MENU 8 9 10 1 Navigation keys Navigate through menus and make selections. 2 Power button Turn the projector on and off. 3 Power status light Indicates the power status of the projector. 4 Lamp status light Indicates the projector lamp status. 5 Temperature status light Indicates the projector temperature status.
About MimioProjector About the Remote Control The following figure shows the components of the MimioProjector remote control.
About MimioProjector 12 1 Source Select an input signal. 2 Resync Automatically synchronize the PC analog timing to the optimized condition. 3 HDMI Switch to HDMI input. 4 Video Switch to Composite Video or SVideo input. 5 3D Turn on and off the 3D menu. 6 Menu Open the menu screen or exit a menu. 7 Freeze Freeze or unfreeze the image on the screen. 8 Blank Hide or show the screen image. 9 Power Turn the projector on or off. 10 PC Switch to VGA-A/VGA-B input.
About MimioProjector About the Connection Ports The following figure shows the connection ports available on the MimioProjector . 1 10 3 2 11 4 12 5 6 13 14 7 8 9 15 16 1 Mini-USB 9 Audio output 2 HDMI 10 12V trigger relay (12V, 250mA) 3 VGA output 11 RS232 4 VGA in 1 12 VGA in 2 5 Audio in 1 (for VGA in 1) 13 Audio in 2 (for VGA in 2) 6 S-Video 14 Composite video input 7 Left/Right RCA audio input (for composite video input) 15 3.
This page intentionally left blank for double-sided printing.
Chapter 2 Getting Started Review the following topics to install and start using your MimioProjector. n Connecting the Projector n Setting Up the Remote Control n Turning On the Power Connecting the Projector You can connect MimioProjector to a computer or other video source..
Getting Started Connecting to a Computer The following figure shows the connection methods available for connecting the MimioProjector to a computer.
Connecting the Projector Connecting to a Video Source The following figure shows the connection methods available for connecting the MimioProjector to a video source.
Getting Started Setting Up the Remote Control Before using the remote control for the first time, remove the transparent insulation tape. To set up the remote control 1. Press firmly and slide the battery holder out of the battery compartment. 2. Remove the battery from the battery holder. 25 20 LT R O C S 3. Remove the transparent insulation tape. 3V 20 S O C R LT 25 4. Replace the battery holder with the + polarity marking facing up as shown. 3V 18 25 LT R 20 O C M S 5.
Turning On the Power Turning On the Power The projector has an auto-off feature which automatically turns the projector off when no input signal is received by the projector for a set amount of time. For information about setting the amount of time the projector will stay on before automatically turning off , see Auto Power Off on page 28. To turn the projector on 1. Securely connect the power cord and signal cable. When connected, the Power status light turns red. 2.
Getting Started Turning off the Power To turn the projector off 1. Press on the control panel or on the remote control. A confirmation message is displayed on the projector screen. 2. Press again to turn the projector off. The Power status light turns red and blinks rapidly. The projector fans continue to run for approximately 10 seconds to ensure that the projector cools properly.
Turning On the Power Status Lights Message Lamp status light Red Temperature status light Red Power status light Red Power status light Blue Power plug Flash ON to OFF 100ms Flash ON to OFF 100ms Flash ON to OFF 100ms -- Standby -- -- ON -- Power button ON -- -- -- ON -- Cooling state -- -- 0.5 second H (ON) 0.5 second L (OFF) flashing Power button OFF Cooling completed; Standby mode -- -- ON -- ON ON ON -- -- ON -- ON -- 0.5 second H (ON) 0.
Getting Started Adjusting the Projected Image You can adjust the size and focus of the projected image. Resizing the Projected Image The size of the projected image depends on the distance of the projector from the screen. The following table describes the general guidelines for projector distance from the screen. Screen Size (16:10) Projection Distance (A) Projection Distance (B) Diagonal (inch) mm Inch mm Inch mm 70 1778 20.4 517 7.2 182 80 2032 23.5 596 10.3 262 87.2 2215 25.
Chapter 3 Changing the Projector Settings You can adjust the projector image and change the projector settings using the projector menus. The projector automatically detects the input source. To change the projector settings 1. Press Menu on the control panel or on the remote control to display the projector main menu. 2. Use the navigation keys to select the desired menu item. 3.
Changing the Projector Settings Main Menu Submenu Settings SCREEN Aspect Ratio AUTO / 4:3 / 16:9 / 16:10 Phase 0~31 Clock -50~50 H. Position -10~10 V.
Navigating the Projector Menu Main Menu Submenu Settings OPTIONS Logo Default / User Logo Capture Auto source Off / On Input HDMI / VGA-A / VGA-B / S-Video / COMPOSITE Auto Power Off (min) 0~120 Lamp Setting Lamp Hours Used (Normal) Lamp Hours Used (ECO) Lamp Life Reminder Off / On Lamp Power Mode ECO / Normal / Extreme Dimming Clear Lamp Hours No / Yes Dynamic Black Off / On High Altitude Off / On Dust Filter Reminder Filters Remind (Hour) Cleaning Up Reminder Information No / Ye
Changing the Projector Settings Main Menu 3D Submenu Settings 3D AUTO / Off / On 3D Invert Off / On 3D Format Frame Packing / Side-by-Side (Half) / Top and Bottom / Frame Sequential / Field Sequential 1080p @ 24 INTERACTIVE 96Hz / 144Hz Interactive Settings Off / IR Camera Adjusting the 3D Settings You can adjust the 3D settings for your projector. 3D You can choose how the projector handles 3D images. n Auto - select the 3D image automatically whenever an HDMI 1.
Adjusting the Interactive Settings Adjusting the Interactive Settings Use this setting to turn on and off the Interactive Pen function. n IR Camera - the Interactive Pen function is on n Off - the Interactive Pen function is off Before turning on Interactive, unplug the mini-USB cable that connects your computer to the projector. After turning on Interactive, plug the mini-USB cable back in. Notes l This feature is only available when displaying images from HDMI/VGA input.
Changing the Projector Settings Logo Capture You can capture an image to display on projector startup. Press ► to capture the image currently displayed on the screen. Notes l Ensure that the displayed image does not exceed the native resolution of the projector (WXGA:1280x800). l Logo Capture is not available when 3D is enabled. l The aspect ratio should be set to Auto before using capturing an image.
Adjusting the Options Lamp Power Mode The following lamp power modes are available: n Normal - the projector lamp is at full brightness n ECO - the projector lamp is dimmed to reduce power consumption, extending the life of the lamp n Extreme Dimming - the projector lamp is dimmed 30 percent to reduce power consumption, extending the life of the lamp Clear Lamp Hours Reset the lamp hours counter after replacing the projector lamp.
Changing the Projector Settings Information Display the following projector information: n Model name n Software version n SNID n Color space n Source n Aspect ratio n Resolution Adjusting the Picture Many settings are available for adjusting the picture displayed by the projector.. Color Mode The following optimized color modes are available for viewing various types of images.
Adjusting the Screen Saturation Adjust the color saturation of the image. The saturation ranges from black and white to fully saturated color. This setting is only supported when Movie is selected as the color mode. Press ◄ to decrease the amount of saturation in the image. Press ► to increase the amount of saturation in the image. Hue Adjust the red and green color balance. This setting is only supported when Movie is selected as the color mode. Press ◄ to increase the amount of green in the image.
Changing the Projector Settings Phase Change the signal timing of the display to match the timing of the graphics card for your computer. If the image appears unstable or flickers, use this setting to correct it. Press ◄ to decrease the signal timing. Press ► to increase the signal timing. Clock Change the display data frequency to match the frequency of the graphics card for your computer. Adjust this setting only if the image appears to flicker vertically. Press ◄ to decrease the data frequency.
Adjusting the General Settings Adjusting the General Settings You can adjust many of the general settings for your projector. Language Select the language to use when displaying the projector menus. Menu Location Select the location for the projector menu to display. Top left Top right Center Bottom left Bottom right Closed Caption The following closed caption options are available: n Off n CC1 n CC2 n CC3 n CC4.
Changing the Projector Settings Test Pattern You can display a test pattern to test the image settings. n On - show the test pattern n Off - hide the test pattern Security You can choose to require a password to be entered each time the projector is turned on.
Adjusting the Volume Adjusting the Volume You can adjust the projector volume settings. Mute You can choose to mute the projector audio. You can also press Mute on the remote control to turn mute on and off. Volume Use this setting to increase or decrease the speaker volume. Press ◄ to decrease the volume. Press ► to increase the volume. You can also use the volume buttons on the remote control to adjust the volume. Microphone Volume Use this setting to increase or decrease the microphone volume.
This page intentionally left blank for double-sided printing.
Chapter 4 Caring for MimioProjector Replacing the Remote Control Battery To ensure safe operation, please observe the following precautions : n Use only CR2025 type battery. Using the incorrect battery type may cause explosion. n Avoid contact with water or liquid. n Do not expose the remote control to moisture or heat. n Do not drop the remote control. n If the battery leaks while inserted in the remote control, carefully wipe the case clean and install new battery.
Caring for MimioProjector Replacing the Lamp The projector automatically detects the lamp life. When the lamp is nearing the end of life, a warning is displayed on the screen. When the warning appears, contact Mimio Customer Support to order a replacement lamp as soon as possible. Make sure the projector is off and has cooled down for at least 60 minutes before changing the lamp. Notes l The screws on the lamp cover and the lamp cannot be removed.
Cleaning the Dust Filters 6. Press the power button to turn on the projector. 7. Clear the lamp hours. See Clear Lamp Hours on page 29for information about clearing the lamp hours. Cleaning the Dust Filters The dust filters should be cleaned after every 500 hours of use. Clean the filters more frequently if the projector is used in a dusty environment. When the dust filters need to be cleaned, a warning is displayed on the screen. When the warning appears, clean the dust filters as soon as possible.
This page intentionally left blank for double-sided printing.
Getting Help Review this chapter if you encounter a problem with your projector. If you are unable to solve a problem, this chapter also describes how to contact Mimio Technical Support. General Troubleshooting Review this section if you encounter a general problem with your projector. Projector stops responding to all controls 1. Press the power button to turn the projector off. 2. Unplug the power cord. 3. After 20 seconds, or longer, plug the power cord back in. 4.
Notebook Brand Function Keys Acer [Fn]+[F5] Asus [Fn]+[F8] Dell [Fn]+[F8] Gateway [Fn]+[F4] IBM/Lenovo [Fn]+[F7] HP/Compaq [Fn]+[F4] NEC [Fn]+[F3] Toshiba [Fn]+[F5] Mac Apple System Preference -> Display -> Arrangement -> Mirror display The notebook computer display is not displaying an image Some notebook computers may deactivate the screens when a second display device is in use. Each has a different way to be reactivated.
Image is displayed with slanted sides n If possible, reposition the projector so that the image is centered on the screen. n Adjust the vertical keystone setting on the projector. See Vertical Keystone on page 32 for information about adjusting this setting. Image is reversed Verify that the ceiling mount setting on the projector is set correctly. See Ceiling Mount on page 32for information about adjusting this setting. 3D Troubleshooting Review this section if you encounter a problem with 3D mode.
Contacting Mimio Mimio maintains an Internet Web site that offers support for MimioClassroom products. In addition, Mimio’s Technical Support department is available by phone. Web site: www.mimio.com Phone: (877) 846-3721 Visit the Support section of our Web site at www.mimio.com to contact us by email.
Chapter 6 Compatibility Modes VGA Analog PC Signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] VGA 640x480 60 31.5 640x480 67 35.0 640x480 72 37.9 640x480 75 37.5 640x480 85 43.3 640x480 120 61.9 IBM 720x400 70 31.5 SVGA 800x600 56 35.1 800x600 60 37.9 800x600 72 48.1 800x600 75 46.9 800x600 85 53.7 800x600 120 77.4 Apple, MAC II 832x624 75 49.1 XGA 1024x768 60 48.4 1024x768 70 56.5 1024x768 75 60.0 1024x768 85 68.7 1024x768 120 99.
Compatibility Modes Modes Resolution V. Frequency [Hz] H. Frequency [Hz] Apple, MAC II 1152x870 75 68.7 SXGA 1280x1024 60 64.0 1280x1024 72 77.0 1280x1024 75 80.0 1280x960 60 60.0 1280x960 75 75.2 SXGA+ 1400x1050 60 65.3 UXGA 1600x1200 60 75.0 Modes Resolution V. Frequency [Hz] H. Frequency [Hz] WXGA 1280x720 60 44.8 1280x800 60 49.6 1366x768 60 47.7 1440x900 60 59.9 1680x1050 60 65.
VGA Analog Component Signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 480i 720x480(1440x480) 59.94(29.97) 15.7 576i 720x576(1440x576) 50(25) 15.6 480p 720x480 59.94 31.5 576p 720x576 50 31.3 720p 1280x720 60 45.0 1280x720 50 37.5 1920x1080 60(30) 33.8 1920x1080 50(25) 28.1 1920x1080 23.98/24 27.0 1920x1080 60 67.5 1920x1080 50 56.
Compatibility Modes HDMI Digital PC Signal 48 Modes Resolution V. Frequency [Hz] H. Frequency [Hz] VGA 640x480 60 31.5 640x480 67 35.0 640x480 72 37.9 640x480 75 37.5 640x480 85 43.3 640x480 120 61.9 IBM 720x400 70 31.5 SVGA 800x600 56 35.1 800x600 60 37.9 800x600 72 48.1 800x600 75 46.9 800x600 85 53.7 800x600 120 77.4 Apple, MAC II 832x624 75 49.1 XGA 1024x768 60 48.4 1024x768 70 56.5 1024x768 75 60.0 1024x768 85 68.7 1024x768 120 99.
HDMI Digital Modes Resolution V. Frequency [Hz] H. Frequency [Hz] Apple, MAC II 1152x870 75 68.7 SXGA 1280x1024 60 64.0 1280x1024 72 77.0 1280x1024 75 80.0 1280x960 60 60.0 1280x960 75 75.2 SXGA+ 1400x1050 60 65.3 UXGA 1600x1200 60 75.0 Modes Resolution V. Frequency [Hz] H. Frequency [Hz] WXGA 1280x720 60 44.8 1280x800 60 49.6 1366x768 60 47.7 1440x900 60 59.9 1680x1050 60 65.
Compatibility Modes Video Signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 480p 640x480 59.94/60 31.5 480i 720x480(1440x480) 59.94(29.97) 15.7 576i 720x576(1440x576) 50(25) 15.6 480p 720x480 59.94 31.5 576p 720x576 50 31.3 720p 1280x720 60 45.0 1280x720 50 37.5 1920x1080 60(30) 33.8 1920x1080 50(25) 28.1 1920x1080 23.98/24 27.0 1920x1080 60 67.5 1920x1080 50 56.3 Resolution V. Frequency [Hz] H. Frequency [Hz] 720p 50 31.5 720p 59.94/60 15.
Chapter 7 Technical and Environmental Information This chapter contains technical information for the MimioProjector. For product specifications and compliance information, visit the Documentation section of the Support area of our Web site at www.mimio.com. Usage Notice Follow all warnings, precautions, and maintenance as recommended in this user guide. Warnings n Do not look into the projector lens when the lamp is on. The bright light may hurt and damage your eyes.
Technical and Environmental Information Do not do the following n Clean the lens. n Block the ventilation slots and openings on the unit. n Use abrasive cleaners, waxes, or solvents to clean the unit. n Use under the following conditions: l In extremely hot, cold, or humid environments. l Ensure that the ambient room temperature is between 5°C - 40°C. l Ensure relative humidity is a maximum of 80%, non-condensing. l In areas susceptible to excessive dust and dirt.
Projector Mount Saftey Notices Operating Conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian Users This Class B digital apparatus complies with Canadian ICES-003.
Technical and Environmental Information l Do not install the product in an area subject to direct exposure to bright light; doing so may cause eye fatigue when viewing the display panel. n Do not modify any accessory or use broken parts. Contact Mimio Customer Support with any questions. n Tighten all screws, but do not apply excessive torque to any screw. Excessive torque may break or damage the screw or screw threads. n The wall mount is rated for a maximum load of 15 Kg (33 Ibs.).
Documentation Feedback Documentation Feedback We are constantly working to produce the highest quality documentation for our products. We welcome your feedback. Send us your comments or suggestions about our online Help, printed, or PDF manuals.
