User Guide

9
FRONT
L
R
IN OUT
REAR
L
R
IN OUT
CENTER
OUT
IN
LFE
OUT
IN
MULTI-CHANNEL
PREAMP
LD/DVD
C
S
In Out In Out In Out
FRONT REAR
OUT
IN
DIGITAL I/O
L
R
L
R
DIGITAL OUT
(Optical)
LD/DVD Player
FRONT AMP
L
R
L
R
IN
SURROUND AMP
L
R
L
R
IN
CENTER/SUB AMP
C
S
C
S
IN
DIGITAL OUT
(Coaxial)
CD Player
Out
L
R
Out
L
R
In
CD
POWER
SERIAL #
12 VOLTS DC
SYSTEMDIGITAL I/0LFECENTERREARFRONT
OUT
IN
OUT
IN
OUTL
INR
L
R
IN OUT IN OUT
CONFIGURATION
1 8
1 2 3 4 5 6 7 8
Dip On
DTS Decoding Under License from
DTS Technology LLC
U.S. Patent Number 5,451,942
Designed & Engineered in the USA
INCLINE VILLAGE
NV 89452-8359
US & FOREIGN PATENTS PENDING
Design verified to comply with FCC
Part 15 for a Class B Digital Device
AUTO MODE
Installation with Multi-channel Preamp and Two Sources
In this configuration the Millennium 2.4.6 is installed within an existing sound system
that uses a multi-channel A/V Preamp and separate amplifiers. The illustration shows
two digital source devices hooked up to the 2.4.6, one via a coaxial input, the other via an
optical input. This installation allows you to play non-DTS encoded material, directly from the
Preamp. When the material is DTS encoded all you have to do is turn on the 2.4.6, verify that
it is in the Auto mode, switch on and play your chosen digital source device.
