User Guide

7
CENTER/SUB AMP
C
S
C
S
SURROUND AMP
L
R
L
R
FRONT AMP
L
R
FRONT
L
R
IN OUT
REAR
L
R
IN OUT
L
R
CENTER
OUT
IN
LFE
OUT
IN
IN
IN
IN
DIGITAL OUT
(Coaxial)
CD Player
DIGITAL OUT
(Optical)
LD/DVD Player
OUT
IN
DIGITAL I/O
POWER
SERIAL #
12 VOLTS DC
SYSTEMDIGITAL I/0LFECENTERREARFRONT
OUT
IN
OUT
IN
OUTL
INR
L
R
IN OUT IN OUT
CONFIGURATION
1 8
1 2 3 4 5 6 7 8
Dip On
DTS Decoding Under License from
DTS Technology LLC
U.S. Patent Number 5,451,942
Designed & Engineered in the USA
INCLINE VILLAGE
NV 89452-8359
US & FOREIGN PATENTS PENDING
Design verified to comply with FCC
Part 15 for a Class B Digital Device
MANUAL MODE
Stand Alone Installation with Two Sources
In this configuration the Millennium 2.4.6
is being used as both a DTS decoder and
a preamp. This is particularly useful in
dedicated DTS systems or where there are
only two digital source devices. It does,
however, require that one of those sources
have an optical digital output and the other
must have a coaxial digital output
