User's Manual

MWC-713 User Manual
Miliwave 4 / 5
1.3 MWC-713 Module Description
The Miliwave's MWC-713 module in conjunction with the Host Communication Processor board can
function as a PTP or PTMP bridge communication . Main chracteristics of the MWC-713 module include:
- Adaptive Modulation and Link Adaptation: Up to 16QAM and MCS1-12 support
- Air Gap Phased Array Planar Antena: EIRP 36dBm,
- Beam sweep range : Elevation 60°, Azimuth 60°
- Advanced Security: AES-128
- Compact Form Factor: 52mm x 55mm x14mm
- Connectivity: USB 3.0 Type-C, 60GHz wireless
2. Technical Specifications
- Aggregate capacity: Upto 1.4 Gbps uni-directional, Upto 2.8 Gbps bi-directional
- Latency : less than 1 millisecond round-trip
- Security: AES-128
- I/O interface: USB 3.0(Type-C)
- Other Interface: LEDs indicators for connection status
3.0 Radio Specifications
- Access Technlogy: Single Carrier beam-forming physical layer
- Time Division Duplex
- Frequencies: 59.40 ~ 65.88GHz
- Channel Bandwidth: 2.16 GHz
- Antenna:4x8 Air gap Phased Array Planar Antena beam-forming with 60 degree horizontal and 60
degree vertical
- EIRP: 36 dBm
4.0 Mechanical, Power and Environmental Specification
- Dimension: 52mm x 55mm x14m
- Weight: 96g
- Power Consumption: 4W(Max)
- Operating Temperature: -40ºC ~ +85ºC
- Humidity: 5%~95%
5.0 Module Throughput
- MCS Index : 1-12,
- Modulation: BPSK,QPSK,16QAM
- Data Rate : Max PHY rate 4620 Mbit/s
6.0 Installation
The MWC-713 could only be installed with Host Communication Processor board at the factory level.
There is no user serviceable parts in the MWC-713 module
