After all conguration is done, nal step
allows you to do just a bit more.
Step 4 - Finishing
Figure 3-7: Choose whether to open Edit Project window after dialog closes.
02
01
01
There is a check-box called “Open Edit
Project window to set Conguration
bits” at the nal step. Edit Project is a
specialized window which allows you to
do all the necessary oscillator and PLL
settings. We made sure that everything
is described in plain English, so you
will be able to do the settings without
having to open the datasheet. Anyway,
since we are only building a simple
application, we will leave it at default
conguration (internal 16MHz oscillator
with PLL disabled). Therefore, leave
the checkbox unchecked.
Click Finish.
