Touch Panel TFT Library
The mikroC PRO for PIC32 provides a library for working with Touch Panel for TFT.
Library Dependency Tree
External dependencies of Touch Panel TFT Library
The following variables must be dened in all
projects using Touch Panel TFT Library: Description: Example:
extern sfr sbit DriveX_Left;
DriveX_Left line.
sbit DriveX_Left at LATB13_
bit;
extern sfr sbit DriveX_Right;
DriveX_Right line.
sbit DriveX_Right at LATB11_
bit;
extern sfr sbit DriveY_Up;
DriveY_Up line.
sbit DriveY_Up at LATB12_
bit;
extern sfr sbit DriveY_Down;
DriveY_Down line.
sbit DriveY_Down at LATB10_
bit;
extern sfr sbit DriveX_Left_Direction;
Direction of the DriveX_Left pin.
sbit DriveX_Left_Direction
at TRISB13_bit;
extern sfr sbit DriveX_Right_Direction;
Direction of the DriveX_Right pin.
sbit DriveX_Right_Direction
at TRISB11_bit;
extern sfr sbit DriveY_Up_Direction;
Direction of the DriveY_Up pin.
sbit DriveY_Up_Direction at
TRISB12_bit;
extern sfr sbit DriveY_Down_Direction;
Direction of the DriveY_Down pin.
sbit DriveY_Down_Direction
at TRISB10_bit;
Library Routines
- TP_TFT_Init
- TP_TFT_Set_ADC_Threshold
- TP_TFT_Press_Detect
- TP_TFT_Get_Coordinates
- TP_TFT_Calibrate_Min
- TP_TFT_Calibrate_Max
- TP_TFT_Get_Calibration_Consts
- TP_TFT_Set_Calibration_Consts
