User manual

Table Of Contents

mikroC PRO for PIC32

MikroElektronika

583

TP_Get_Calibration_Consts

Prototype

void TP_Get_Calibration_Consts(unsigned int *x_min, unsigned int *x_max,

unsigned int *y_min, unsigned int *y_max);

Description Gets calibration constants after calibration is done and stores them in x_min, x_max, y_min and

y_max parameters.

Parameters - x_min: x coordinate of the bottom left corner of the working area.

- x_max: x coordinate of the upper right corner of the working area.

- y_min: y coordinate of the bottom left corner of the working area.

- y_max: y coordinate of the upper right corner of the working area.

Returns Nothing.

Requires Nothing.

Example

TP_Get_Calibration_Consts(&x_min, &y_min, &x_max, &y_max); // Get

calibration constants

Notes None.

TP_Set_Calibration_Consts

Prototype

void TP_Set_Calibration_Consts(unsigned int x_min, unsigned int x_max,

unsigned int y_min, unsigned int y_max);

Description Sets calibration constants.
