T6963C_cursor_blink
Prototype
void T6963C_cursor_blink(unsigned int n);
Description Enable/disable cursor blinking.
Parameters - n: cursor blinking enable/disable parameter. Valid values: 0 (disable cursor blinking) and 1 (enable
cursor blinking).
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
// enable cursor blinking
T6963C_cursor_blink(1);
Notes None.
Library Example
The following drawing demo tests advanced routines of the T6963C Glcd library. Hardware congurations in this
example are made for the LV-32MX v6 board and PIC32MX460F512L.
Copy Code To Clipboard
#include “__T6963C.h”
// T6963C module connections
unsigned long T6963C_dataPort at PORTD; // DATA port
unsigned long T6963C_cntlPort at PORTE; // CTRL port
sbit T6963C_ctrlwr at LATE2_bit; // WR write signal
sbit T6963C_ctrlrd at LATE1_bit; // RD read signal
sbit T6963C_ctrlcd at LATE0_bit; // CD command/data signal
sbit T6963C_ctrlrst at LATE4_bit; // RST reset signal
sbit T6963C_ctrlwr_Direction at TRISE2_bit; // WR write signal
sbit T6963C_ctrlrd_Direction at TRISE1_bit; // RD read signal
sbit T6963C_ctrlcd_Direction at TRISE0_bit; // CD command/data signal
sbit T6963C_ctrlrst_Direction at TRISE4_bit; // RST reset signal
// Signals not used by library, they are set in main function
sbit T6963C_ctrlce at LATE3_bit; // CE signal
sbit T6963C_ctrlfs at LATE6_bit; // FS signal
sbit T6963C_ctrlmd at LATE5_bit; // MD signal
sbit T6963C_ctrlce_Direction at TRISE3_bit; // CE signal direction
sbit T6963C_ctrlfs_Direction at TRISE6_bit; // FS signal direction
sbit T6963C_ctrlmd_Direction at TRISE5_bit; // MD signal direction
// End T6963C module connections
/*
* bitmap pictures stored in ROM
*/
const code char mikroE_240x128_bmp[];
const code char einstein[];
