T6963C_setGrPanel
T6963C_setTxtPanel
T6963C_panelFill
Prototype
void T6963C_setGrPanel(unsigned int n);
Description Compute start address for selected graphic panel and set appropriate internal pointers. All subsequent
graphic operations will be preformed at this graphic panel.
Parameters - n: graphic panel number. Valid values: 0 and 1.
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
// set graphic panel 1 as current graphic panel.
T6963C_setGrPanel(1);
Notes None.
Prototype
void T6963C_setTxtPanel(unsigned int n);
Description Compute start address for selected text panel and set appropriate internal pointers. All subsequent
text operations will be preformed at this text panel.
Parameters - n: text panel number. Valid values: 0 and 1.
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
// set text panel 1 as current text panel.
T6963C_setTxtPanel(1);
Notes None.
Prototype
void T6963C_panelFill(unsigned char v);
Description Fill current panel in full (graphic+text) with appropriate value (0 to clear).
Parameters - v: value to ll panel with.
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
clear current panel
T6963C_panelFill(0);
Notes None.
