T6963C_PartialImage
T6963C_sprite
Prototype
void T6963C_PartialImage(unsigned int x_left, unsigned int y_top, unsigned
int width, unsigned int height, unsigned int picture_width, unsigned int
picture_height, code const unsigned short * image);
Description Displays a partial area of the image on a desired location.
Parameters - x_left: x coordinate of the desired location (upper left coordinate).
- y_top: y coordinate of the desired location (upper left coordinate).
- width: desired image width.
- height: desired image height.
- picture_width: width of the original image.
- picture_height: height of the original image.
- image: image to be displayed. Bitmap array can be located in both code and RAM memory (due to
the mikroC PRO for PIC pointer to const and pointer to RAM equivalency).
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See T6963C_init routine.
Example
// Draws a 10x15 part of the image starting from the upper left corner on
the coordinate (10,12). Original image size is 16x32.
T6963C_PartialImage(10, 12, 10, 15, 16, 32, image);
Notes Image dimension must match the display dimension.
Use the integrated Glcd Bitmap Editor (menu option Tools › Glcd Bitmap Editor) to convert image to
a constant array suitable for displaying on Glcd.
Prototype
void T6963C_sprite(unsigned char px, unsigned char py, const code char *pic,
unsigned char sx, unsigned char sy);
Description Fills graphic rectangle area (px, py) to (px+sx, py+sy) with custom size picture.
Parameters - px: x coordinate of the upper left picture corner. Valid values: multiples of the font width
- py: y coordinate of the upper left picture corner
- pic: picture to be displayed
- sx: picture width. Valid values: multiples of the font width
- sy: picture height
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_sprite(76, 4, einstein, 88, 119); // draw a sprite
Notes If px and sx parameters are not multiples of the font width they will be scaled to the nearest lower
number that is a multiple of the font width.
