T6963C_circle_ll
T6963C_image
Prototype
void T6963C_circle_ll(int x, int y, long r, unsigned char pcolor);
Description Draws a lled circle on Glcd.
Parameters - x: x coordinate of the circle center
- y: y coordinate of the circle center
- r: radius size
- pcolor: color parameter. Valid values: T6963C_BLACK and T6963C_WHITE
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_circle_ll(120, 64, 110, T6963C_WHITE);
Notes None.
Prototype
void T6963C_image(const code char *pic);
Description Displays bitmap on Glcd.
Parameters - pic: image to be displayed. Bitmap array can be located in both code and RAM memory (due to the
mikroC PRO for PIC32 pointer to const and pointer to RAM equivalency).
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_image(my_image);
Notes Image dimension must match the display dimension.
Use the integrated Glcd Bitmap Editor (menu option Tools › Glcd Bitmap Editor) to convert image to
a constant array suitable for displaying on Glcd.
