T6963C_rectangle
T6963C_rectangle_round_edges
Prototype
void T6963C_rectangle(int x0, int y0, int x1, int y1, unsigned char
pcolor);
Description Draws a rectangle on Glcd.
Parameters - x0: x coordinate of the upper left rectangle corner
- y0: y coordinate of the upper left rectangle corner
- x1: x coordinate of the lower right rectangle corner
- y1: y coordinate of the lower right rectangle corner
- pcolor: color parameter. Valid values: T6963C_BLACK and T6963C_WHITE
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_rectangle(20, 20, 219, 107, T6963C_WHITE);
Notes None.
Prototype
void T6963C_rectangle_round_edges(int x0, int y0, int x1, int y1, int round_
radius, unsigned char pcolor);
Description Draws a rounded edge rectangle on Glcd.
Parameters - x0: x coordinate of the upper left rectangle corner
- y0: y coordinate of the upper left rectangle corner
- x1: x coordinate of the lower right rectangle corner
- y1: y coordinate of the lower right rectangle corner
- round_radius: radius of the rounded edge.
- pcolor: color parameter. Valid values: T6963C_BLACK and T6963C_WHITE
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_rectangle_round_edges(20, 20, 219, 107, 12, T6963C_WHITE);
Notes None.
