T6963C_ll
T6963C_dot
Prototype
void T6963C_ll(unsigned char v, unsigned int start, unsigned int len);
Description Fills controller memory block with given byte.
Parameters - v: byte to be written
- start: starting address of the memory block
- len: length of the memory block in bytes
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_ll(0x33,0x00FF,0x000F);
Notes None.
Prototype
void T6963C_dot(int x, int y, unsigned char color);
Description Draws a dot in the current graphic panel of Glcd at coordinates (x, y).
Parameters - x: dot position on x-axis
- y: dot position on y-axis
- color: color parameter. Valid values: T6963C_BLACK and T6963C_WHITE
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_dot(x0, y0, pcolor);
Notes None.
