Example
// T6963C module connections
char T6963C_dataPort at PORTB; // DATA port
sbit T6963C_ctrlwr at LATF2_bit; // WR write signal
sbit T6963C_ctrlrd at LATF1_bit; // RD read signal
sbit T6963C_ctrlcd at LATF0_bit; // CD command/data signal
sbit T6963C_ctrlrst at LATF4_bit; // RST reset signal
sbit T6963C_ctrlwr_Direction at TRISF2_bit; // WR write signal
sbit T6963C_ctrlrd_Direction at TRISF1_bit; // RD read signal
sbit T6963C_ctrlcd_Direction at TRISF0_bit; // CD command/data signal
sbit T6963C_ctrlrst_Direction at TRISF4_bit; // RST reset signal
// Signals not used by library, they are set in main function
sbit T6963C_ctrlce at LATF3_bit; // CE signal
sbit T6963C_ctrlfs at LATF6_bit; // FS signal
sbit T6963C_ctrlmd at LATF5_bit; // MD signal
sbit T6963C_ctrlce_Direction at TRISF3_bit; // CE signal direction
sbit T6963C_ctrlfs_Direction at TRISF6_bit; // FS signal direction
sbit T6963C_ctrlmd_Direction at TRISF5_bit; // MD signal direction
// End T6963C module connections
...
// init display for 240 pixel width, 128 pixel height and 8 bits character
width
T6963C_init(240, 128, 8);
Notes None.
T6963C_writeData
Prototype
void T6963C_writeData(unsigned char mydata);
Description Writes data to T6963C controller.
Parameters - mydata: data to be written
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See the T6963C_init routine.
Example
T6963C_writeData(AddrL);
Notes None.
