SPI_T6963C_cursor
SPI_T6963C_cursor_blink
Prototype
void SPI_T6963C_cursor(unsigned int n);
Description Set cursor on/off.
Parameters - n: on/off parameter. Valid values: 0 (set cursor off) and 1 (set cursor on).
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See SPI_T6963C_Cong routine.
Example
// set cursor on
SPI_T6963C_cursor(1);
Notes None.
Prototype
void SPI_T6963C_cursor_blink(unsigned int n);
Description Enable/disable cursor blinking.
Parameters - n: cursor blinking enable/disable parameter. Valid values: 0 (disable cursor blinking) and 1 (enable
cursor blinking).
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See SPI_T6963C_Cong routine.
Example
// enable cursor blinking
SPI_T6963C_cursor_blink(1);
Notes None.
Library Example
The following drawing demo tests advanced routines of the SPI T6963C Glcd library. Hardware congurations in this
example are made for the LV-32MX v6 board and PIC32MX460F512L.
Copy Code To Clipboard
#include "__SPIT6963C.h"
/*
* bitmap pictures stored in ROM
*/
const code char mikroE_240x128_bmp[];
const code char einstein[];
// Port Expander module connections
sbit SPExpanderRST at LATD8_bit;
sbit SPExpanderCS at LATD9_bit;
sbit SPExpanderRST_Direction at TRISD8_bit;
sbit SPExpanderCS_Direction at TRISD9_bit;
// End Port Expander module connections
void main() {
#dene COMPLETE_EXAMPLE
#dene LINE_DEMO // Uncomment to demonstrate line drawing routines
