SPI_T6963C_write_text
Prototype
void SPI_T6963C_write_text(unsigned char *str, unsigned char x, unsigned
char y, unsigned char mode);
Description Writes text in the current text panel of Glcd at coordinates (x, y).
Parameters - str: text to be written
- x: text position on x-axis
- y: text position on y-axis
- mode: mode parameter. Valid values: SPI_T6963C_ROM_MODE_OR, SPI_T6963C_ROM_MODE_
XOR, SPI_T6963C_ROM_MODE_AND and SPI_T6963C_ROM_MODE_TEXT
Mode parameter explanation:
- OR Mode: In the OR-Mode, text and graphics can be displayed and the data is logically “OR-ed”. This
is the most common way of combining text and graphics for example labels on buttons.
- XOR-Mode: In this mode, the text and graphics data are combined via the logical “exclusive OR”.
This can be useful to display text in negative mode, i.e. white text on black background.
- AND-Mode: The text and graphic data shown on the display are combined via the logical “AND
function”.
- TEXT-Mode: This option is only available when displaying just a text. The Text Attribute values are
stored in the graphic area of display memory.
For more details see the T6963C datasheet.
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See SPI_T6963C_Cong routine.
Example
SPI_T6963C_write_text(“Glcd LIBRARY DEMO, WELCOME !”, 0, 0, SPI_T6963C_ROM_
MODE_XOR);
Notes None.
