Example
// Port Expander module connections
sbit SPExpanderRST at LATF0_bit;
sbit SPExpanderCS at LATF1_bit;
sbit SPExpanderRST_Direction at TRISF0_bit;
sbit SPExpanderCS_Direction at TRISF1_bit;
// End Port Expander module connections
...
// Initialize SPI module
SPI1_Init();
SPI_T6963C_Cong(240, 64, 8, 0, 0, 1, 3, 4);
Notes None.
SPI_T6963C_writeData
SPI_T6963C_writeCommand
Prototype
void SPI_T6963C_writeData(unsigned char data_);
Description Writes data to T6963C controller via SPI interface.
Parameters - data_: data to be written
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See SPI_T6963C_Cong routine.
Example
SPI_T6963C_writeData(data_);
Notes None.
Prototype
void SPI_T6963C_writeCommand(unsigned char data_);
Description Writes command to T6963C controller via SPI interface.
Parameters - data_: command to be written
Returns Nothing.
Requires Toshiba Glcd module needs to be initialized. See SPI_T6963C_Cong routine.
Example
SPI_T6963C_writeCommand(SPI_T6963C_CURSOR_POINTER_SET);
Notes None.
