SPI_Glcd_Rectangle_Round_Edges
SPI_Glcd_Rectangle_Round_Edges_Fill
Prototype
void SPI_Glcd_Rectangle_Round_Edges(unsigned short x_upper_left, unsigned
short y_upper_left, unsigned short x_bottom_right, unsigned short y_bottom_
right, unsigned short round_radius, unsigned short color);
Description Draws a rounded edge rectangle on Glcd.
Parameters - x_upper_left: x coordinate of the upper left rectangle corner. Valid values: 0..127
- y_upper_left: y coordinate of the upper left rectangle corner. Valid values: 0..63
- x_bottom_right: x coordinate of the lower right rectangle corner. Valid values: 0..127
- y_bottom_right: y coordinate of the lower right rectangle corner. Valid values: 0..63
- round_radius: radius of the rounded edge.
- color: color parameter. Valid values: 0..2
Returns Nothing.
Requires Glcd needs to be initialized, see SPI_Glcd_Init routine.
Example
// Draw a rounded edge rectangle between dots (5,5) and (40,40) with the
radius of 12
SPI_Glcd_Rectangle_Round_Edges(5, 5, 40, 40, 12, 1);
Notes None.
Prototype
void SPI_Glcd_Rectangle_Round_Edges_Fill(unsigned short x_upper_left,
unsigned short y_upper_left, unsigned short x_bottom_right, unsigned short
y_bottom_right, unsigned short round_radius, unsigned short color);
Description Draws a lled rounded edge rectangle on Glcd with color.
Parameters - x_upper_left: x coordinate of the upper left rectangle corner. Valid values: 0..127
- y_upper_left: y coordinate of the upper left rectangle corner. Valid values: 0..63
- x_bottom_right: x coordinate of the lower right rectangle corner. Valid values: 0..127
- y_bottom_right: y coordinate of the lower right rectangle corner. Valid values: 0..63
- round_radius: radius of the rounded edge
- color: color parameter. Valid values: 0..2
The parameter color determines the color of the rectangle border: 0 white, 1 black, and 2 inverts
each dot.
Returns Nothing.
Requires Glcd needs to be initialized, see SPI_Glcd_Init routine.
Example
// Draws a lled rounded edge rectangle between dots (5,5) and (40,40) with
the radius of 12
SPI_Glcd_Rectangle_Round_Edges_Fill(5, 5, 40, 40, 12, 1);
Notes None.
