Returns Nothing.

Requires Global variables:

- SPI_Ethernet_24j600_CS: Chip Select line

- SPI_Ethernet_24j600_CS_Direction: Direction of the Chip Select pin

must be dened before using this function.

The SPI module needs to be initialized. See the SPIx_Init and SPIx_Init_Advanced routines.

Example

#include “__EthEnc24J600.h”

// mE ethernet NIC pinout

sfr sbit SPI_Ethernet_24j600_CS at RF1_bit;

sfr sbit SPI_Ethernet_24j600_CS_Direction at TRISF1_bit;

// end ethernet NIC denitions

unsigned char myMacAddr[6] = {0x00, 0x14, 0xA5, 0x76, 0x19, 0x3f}; // my MAC

address

unsigned char myIpAddr = {192, 168, 1, 60 }; // my IP addr

SPI1_Init();

SPI_Ethernet_24j600_Init(myMacAddr, myIpAddr, SPI_Ethernet_24j600_MANUAL_

NEGOTIATION & SPI_Ethernet_24j600_FULLDUPLEX & SPI_Ethernet_24j600_

SPD100);

Notes None.
