Soft_SPI_Init
Prototype
void Soft_SPI_Init();
Description Routine initializes the software SPI module.
Parameters None.
Returns Nothing.
Requires Global variables:
- SoftSpi_SDI: Data in line
- SoftSpi_SDO: Data out line
- SoftSpi_CLK: Data clock line
- SoftSpi_SDI_Direction: Direction of the Data in pin
- SoftSpi_SDO_Direction: Direction of the Data out pin
- SoftSpi_CLK_Direction: Direction of the Data clock pin
must be dened before using this function.
Example
// Software SPI module connections
sbit SoftSpi_SDI at RF4_bit;
sbit SoftSpi_SDO at LATF3_bit;
sbit SoftSpi_CLK at LATF6_bit;
sbit SoftSpi_SDI_Direction at TRISF4_bit;
sbit SoftSpi_SDO_Direction at TRISF3_bit;
sbit SoftSpi_CLK_Direction at TRISF6_bit;
// End Software SPI module connections
...
Soft_SPI_Init(); // Init Soft_SPI
Notes None
