Mmc_Fat_QuickFormat
Prototype
unsigned int Mmc_Fat_QuickFormat(char *mmc_fat_label);
Description Formats to FAT16 and initializes MMC/SD card.
Parameters - mmc_fat_label: volume label (11 characters in length). If less than 11 characters are provided, the
label will be padded with spaces. If null string is passed volume will not be labeled
Returns - 0 - if MMC/SD card was detected, successfully formated and initialized
- 1 - if FAT16 format was unseccessful
- 255 - if MMC/SD card was not detected
Requires The appropriate hardware SPI module must be previously initialized.
Example
// Initialize the SPI module
SPI1_Init_Advanced(_SPI_MASTER, _SPI_8_BIT, _SPI_PRESCALE_SEC_1, _SPI_
PRESCALE_PRI_64, _SPI_SS_DISABLE, _SPI_DATA_SAMPLE_MIDDLE, _SPI_CLK_IDLE_
HIGH, _SPI_ACTIVE_2_IDLE);
// Format and initialize MMC/SD card and MMC_FAT16 library globals
Mmc_Fat_QuickFormat(“mikroE”);
// Reinitialize the SPI module at higher speed (change primary prescaler).
SPI1_Init_Advanced(_SPI_MASTER, _SPI_8_BIT, _SPI_PRESCALE_SEC_1, _SPI_
PRESCALE_PRI_4,_SPI_SS_DISABLE, _SPI_DATA_SAMPLE_MIDDLE, _SPI_CLK_IDLE_
HIGH, _SPI_ACTIVE_2_IDLE);
Notes This routine can be used instead or in conjunction with Mmc_Fat_Init routine.
If MMC/SD card already contains a valid boot sector, it will remain unchanged (except volume label
eld) and only FAT and ROOT tables will be erased. Also, the new volume label will be set.
