I2Cx_Init_Advanced
Prototype
void I2Cx_Init_Advanced(unsigned long Fclk_Khz, unsigned long scl);
Description This function congures and initializes the desired I²C module using Peripheral Bus Clock and default
initialization settings.
As per the I²C standard, SCL clock may be 100 kHz or 400 kHz. However, the user can specify any
clock rate up to 1 MHz.
Parameters - Fclk_Khz: Peripheral Bus Clock frequency in kHz.
- scl: requested serial clock rate.
Returns Nothing.
Requires MCU with the I²C module.
Used I²C module must be initialized before using this function. See I2Cx_Init routine.
Example
Notes - I²C library routines require you to specify the module you want to use. To select the desired I²C
module, simply change the letter x in the routine prototype for a number from 1 to 5.
- Number of I²C modules per MCU differs from chip to chip. Please, read the appropriate datasheet
before utilizing this library.
I2Cx_Start
Prototype
void I2Cx_Start();
Description Determines if the I²C bus is free and issues START signal.
Parameters None.
Returns Nothing.
Requires MCU with at least one I²C module.
Used I²C module must be initialized before using this function. See I2Cx_Init routine.
Example
// Issue START signal
I2C1_Start();
Notes - I²C library routines require you to specify the module you want to use. To select the desired I²C
module, simply change the letter x in the routine prototype for a number from 1 to 5.
- Number of I²C modules per MCU differs from chip to chip. Please, read the appropriate datasheet
before utilizing this library.
