S1D13700_Box
Prototype
void S1D13700_Rectangle(unsigned int x0, unsigned int y0, unsigned int x1,
unsigned int y1, unsigned char pcolor);
Returns Nothing.
Description Draws a rectangle on Glcd.
Parameters:
- x0: x coordinate of the upper left rectangle corner.
- y0: y coordinate of the upper left rectangle corner.
- x1: x coordinate of the lower right rectangle corner.
- y1: y coordinate of the lower right rectangle corner.
- pcolor: color parameter. Valid values :
Requires Glcd module needs to be initialized. See the S1D13700_Init routine.
Example
S1D13700_Box(0, 119, 239, 127, S1D13700_WHITE);
Value Description
S1D13700_BLACK
Black color.
S1D13700_WHITE
White color.
S1D13700_Rectangle_Round_Edges
Prototype
void S1D13700_Rectangle_Round_Edges(unsigned int x_upper_left, unsigned int
y_upper_left, unsigned int x_bottom_right, unsigned int y_bottom_right,
unsigned short round_radius, unsigned short color);
Returns Nothing.
Description Draws a rounded edge rectangle on Glcd.
Parameters:
- x_upper_left: x coordinate of the upper left rectangle corner.
- y_upper_left: y coordinate of the upper left rectangle corner.
- x_bottom_right: x coordinate of the lower right rectangle corner.
- y_bottom_right: y coordinate of the lower right rectangle corner.
- round_radius: radius of the rounded edge.
- pcolor: color parameter. Valid values:
Requires Glcd module needs to be initialized. See the S1D13700_Init routine.
Example
S1D13700_Rectangle_Round_Edges(20, 20, 219, 107, 12, S1D13700_WHITE);
Value Description
S1D13700_BLACK
Black color.
S1D13700_WHITE
White color.
