User manual

mikroC PRO for PIC32
MikroElektronika
315
S1D13700_Write_Text
S1D13700_Dot
Prototype
void S1D13700_Write_Text(unsigned char *str, unsigned char x, unsigned char
y, char mode);
Returns Nothing.
Description Writes text in the current text panel of Glcd at coordinates (x, y).
Parameters:
- str: text to be written.
- x: text position on x-axis (column).
- y: text position on y-axis (row).
- mode: mode parameter. Valid values :
Requires Glcd module needs to be initialized. See the S1D13700_Init routine.
Example
S1D13700_Write_Text(“EPSON LIBRARY DEMO, WELCOME !”, 0, 0, S1D13700_OVERLAY_
OR);
Prototype
void S1D13700_Dot(unsigned int x, unsigned int y, unsigned short color);
Returns Nothing.
Description Draws a dot in the current graphic panel of Glcd at coordinates (x, y).
Parameters:
- x: dot position on x-axis.
- y: dot position on y-axis.
- color: color parameter. Valid values :
Requires Glcd module needs to be initialized. See the S1D13700_Init routine.
Example
S1D13700_Dot(50, 50, S1D13700_WHITE);
Value Description
S1D13700_OVERLAY_OR
In the OR-Mode, text and graphics can be displayed and the data is
logically “OR-ed”.
This is the most common way of combining text and graphics, for
example labels on buttons.
S1D13700_OVERLAY_XOR
In this mode, the text and graphics data are combined via the logical
“exclusive OR”.
S1D13700_OVERLAY_AND
The text and graphic data shown on display are combined via the logical
“AND function”.
Value Description
S1D13700_BLACK
Black color.
S1D13700_WHITE
White color.
