S1D13700_Init
Prototype
void S1D13700_Init(unsigned int width, unsigned char height);
Returns Nothing.
Description Initializes S1D13700 Graphic Lcd controller.
Parameters:
- width: width of the Glcd panel.
- height: height of the Glcd panel.
Requires Global variables:
- S1D13700_Data_Port: Data Bus Port.
- S1D13700_WR: Write signal pin.
- S1D13700_RD: Read signal pin.
- S1D13700_A0: Command/Data signal pin.
- S1D13700_RES: Reset signal pin.
- S1D13700_CS: Chip Select signal pin.
- S1D13700_Data_Port_Direction: Data Bus Port Direction.
- S1D13700_WR_Direction: Direction of Write signal pin.
- S1D13700_RD_Direction: Direction of Read signal pin.
- S1D13700_A0_Direction: Direction of Command/Data signal pin.
- S1D13700_RES_Direction: Direction of Reset signal pin.
- S1D13700_CS_Direction: Direction of Chip Select signal pin.
must be dened before using this function.
Example
// S1D13700 module connections
char S1D13700_Data_Port at PORTD;
sbit S1D13700_WR at LATC2_bit;
sbit S1D13700_RD at LATC1_bit;
sbit S1D13700_A0 at LATC0_bit;
sbit S1D13700_RES at LATC4_bit;
sbit S1D13700_CS at LATC5_bit;
char S1D13700_Data_Port_Direction at TRISD;
sbit S1D13700_WR_Direction at TRISC2_bit;
sbit S1D13700_RD_Direction at TRISC1_bit;
sbit S1D13700_A0_Direction at TRISC0_bit;
sbit S1D13700_RES_Direction at TRISC4_bit;
sbit S1D13700_CS_Direction at TRISC5_bit;
// End of S1D13700 module connections
...
// init display for 320 pixel width, 240 pixel height
S1D13700_Init(320, 240);
