mikroICD Debugger Example

Here is a step-by-step mikroICD Debugger Example.

First you have to write a program. We will show how the mikroICD works using this example:

// Lcd module connections

sbit LCD_RS at LATD0_bit;

sbit LCD_EN at LATD1_bit;

sbit LCD_D4 at LATB0_bit;

sbit LCD_D5 at LATB1_bit;

sbit LCD_D6 at LATB2_bit;

sbit LCD_D7 at LATB3_bit;

sbit LCD_RS_Direction at TRISD0_bit;

sbit LCD_EN_Direction at TRISD1_bit;

sbit LCD_D4_Direction at TRISB0_bit;

sbit LCD_D5_Direction at TRISB1_bit;

sbit LCD_D6_Direction at TRISB2_bit;

sbit LCD_D7_Direction at TRISB3_bit;

// End Lcd module connections

char text[] = “mikroElektronika”;

char i;

void Move_Delay() {

Delay_ms(500);

}

void main() {

ADPCFG = 0xFFFF;

Lcd_Init();

Lcd_Cmd(_LCD_CLEAR);

Lcd_Cmd(_LCD_CURSOR_OFF);

for(i = 1; i < 17; i++) {

Lcd_Chr(1, i, text[i-1]);

}
