Datasheet

Page 21
5V
UART
3.3V
GPIO
I2C
AN
SPI
PWM
Angle 3 Click
With AK7451, a mag-
netic rotational angle
sensor with 12-bit
angle resolution.
MIKROE-2755
5V 5V 5V 5V
UART UART UART UART
3.3V 3.3V 3.3V 3.3V
GPIO GPIO GPIO GPIO
I2C I2C I2C I2C
AN AN AN AN
SPI SPI SPI SPI
PWM PWM PWM PWM
BAROMETER Click Bi Hall Click CO Click Color Click
LPS25HB IC, piezore-
sistive absolute pres-
sure sensor. Range
260-1260 hPa.
MIKROE-1817
US2882 bipolar
Hall-eff ect switch and
a 74LVC1T45 single bit,
dual supply transceiver.
MIKROE-1646
MQ-7 gas sensor wi
th
high sensitivity to carbon
monoxide. Detection
range 20ppm-2000ppm.
MIKROE-1626
W
ith TCS3471
(RGBC) color light sensor
and a RGB LED diode.
Resolution up to 16-bits.
MIKROE-1438
SENSORS
