User manual

Introduction to mikromedia+ for Stellaris
®
ARM
®
4
System Specication 4
Package Contains 5
1. Power supply 6
2. LM4F232H5QD microcontroller 8
Key microcontroller features 8
3. Programming the microcontroller 9
Programming with mikroBootloader 10
step 1 – Connecting mikromedia 10
step 2 – Browsing for .HEX le 11
step 3 – Selecting .HEX le 11
step 4 – Uploading .HEX le 12
step 5 – Finish upload 13
Programming with mikroProg
™
programmer 14
mikroProg
™
suite
™
for ARM
®
software 16
Software installation wizard 17
4. RTC Battery and Reset Button 18
5. Crystal oscillator and 2.048V reference 20
6. MicroSD Card Slot 22
7. Touch Screen 24
8. Audio Module 26
9. USB DEVICE connection 28
10. USB HOST connection 30
11. Accelerometer 32
12. Flash Memory 34
13. RF transceiver 36
14. Buzzer 38
15. Other modules 40
16. Pads 42
17. mikromedia+ accessories 44
18. What’s next 46
