OPERATION AND PARTS MANUAL SERIES MODEL MVC-88GE/GEW ONE-WAY PLATE COMPACTOR (ROBIN GASOLINE ENGINE) Revision #1 (1/10/11) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
l PAGE 2 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
NOTE PAGE MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
TABLE OF CONTENTS Multiquip —MVC-88GE/GEW Plate Compactor ROBIN EX170D40050 Engine Table Of Contents .............................................................4 Parts Ordering Procedures ...............................................5 Safety Information ......................................................6--10 Specifications (Compactor/Engine) ................................ 12 General Information ........................................................ 13 Components (Plate Compactor) .............
www.multiquip.com PARTS ORDERING PROCEDURES Ordering parts has never been easier! Choose from three easy options: Order via Internet (Dealers Only): Best Deal! Effective: January 1st, 2006 If you have an MQ Account, to obtain a Username and Password, E-mail us at: parts@multiquip. com. Order parts on-line using Multiquip’s SmartEquip website! ■ View Parts Diagrams ■ Order Parts ■ Print Specification Information To obtain an MQ Account, contact your District Sales Manager for more information.
MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION Do not operate or service the equipment before reading the entire manual. Safety precautions should be followed at all times when operating this equipment. Failure to read and understand the safety messages and operating instructions could result in injury to yourself and others.
MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION GENERAL SAFETY CAUTION NEVER operate this equipment without proper protective clothing, shatterproof glasses, respiratory protection, hearing protection, steel-toed boots and other protective devices required by the job or city and state regulations. NEVER operate this equipment when not feeling well due to fatigue, illness or when under medication. NEVER operate this equipment under the influence of drugs or alcohol.
MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION COMPACTOR SAFETY DANGER NEVER operate the equipment in an explosive atmosphere or near combustible materials. An explosion or fire could result causing severe bodily harm or even death. WARNING NEVER disconnect any emergency or safety devices. These devices are intended for operator safety. Disconnection of these devices can cause severe injury, bodily harm or even death. Disconnection of any of these devices will void all warranties.
MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION FUEL SAFETY BATTERY SAFETY (ELECTRIC START ONLY) DANGER DANGER DO NOT add fuel to equipment if it is placed inside truck bed with plastic liner. Possibility exists of explosion or fire due to static electricity. FUEL DO NOT drop the battery. There is a possibility that the battery will explode. DO NOT expose the battery to open flames, sparks, cigarettes, etc. The battery contains combustible gases and liquids.
MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION TRANSPORTING SAFETY CAUTION NEVER allow any person or animal to stand underneath the equipment while lifting. NOTICE Before lifting, make sure that the equipment parts (hook and vibration insulator) are not damaged and screws are not loose or missing. Always make sure crane or lifitng device has been properly secured to the lifting bail (hook) of the equipment. ALWAYS shutdown engine before transporting.
NOTES MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW PLATE COMPACTOR — SPECIFICATIONS TABLE 1. Specifications (Compactor) Models MVC-88GE/MVC-88GEW Centrifugal Force 3,450 lbs. (1,564.9 kg) Number of Vibrations 5,800 vibrations/min Traveling Speed (GE) Traveling Speed (GEW) 82 ft./min (25 meters/min) 72 ft./min (22 meters/min) Plate Size (W x L) (GE) Plate Size (W x L) (GEW) 19.7 x 20.7 in. (50 x 53 cm) 17 x 22.4 in. (43 x 57 cm) Operating Weight 163 lbs. (74 kg.) Water Tank Capacity (GEW Model Only) 13.7 qt. (13.0 liters) Max.
MVC-88GE/GEW PLATE COMPACTOR — GENERAL INFORMATION Definition of Plate Compactor Frequency/Speed The Mikasa MVC-88GE/GEW is a walk behind, plate compactor designed for the compaction of sand, mixed soils and asphalt. This plate compactor is a powerful compacting tool capable of applying a tremendous force in consecutive high frequency vibrations to a soil surface.
MVC-88GE/GEW PLATE COMPACTOR — COMPONENTS (COMPACTOR) Figure 1. Plate Compactor Controls Figures 1 shows the location of the basic controls and components of the MVC-88GE/GEW Plate Compactor. The function of each control is described below: 6. Belt Cover – Remove this cover to gain access to the Vbelt. NEVER run the compactor without the V-belt cover.
MVC-88GE/GEW PLATE COMPACTOR — COMPONENTS (ROBIN ENGINE) Figure 2. Engine Controls and Components INITIAL SERVICING The engine (Figure 2) must be checked for proper lubrication and filled with fuel prior to operation. Refer to the ROBIN engine service manual for instructions and details for proper operation and servicing. 5. Throttle Lever – Used to adjust engine RPM speed (lever advanced forward SLOW, lever back toward operator FAST). 1. 6. Recoil Starter (pull rope) – Manual-starting method.
MVC-88GE/GEW PLATE COMPACTOR — INSPECTION CAUTION NEVER operate the compactor in a confined area or enclosed area structure that does not provide ample free flow of air. 3. Insert and remove the dipstick without screwing it into the filler neck. Check the oil level shown on the dipstick. 4. If the oil level is low (Figure 4), fill to the edge of the oil filler hole with the recommended oil type (Table 3). Maximum oil capacity is 0.63 quarts (0.60 liters).
MVC-88GE/GEW PLATE COMPACTOR — INSPECTION 2. The V-belt tension is proper if the V-belt bends 10 to 15 mm (Figure 7) when depressed with finger at midway between the clutch and vibration pulley shafts. V-Belt Check CAUTI CAUTION NEVER attempt to check the V-belt with the engine running. Severe injury can occur of your hand (Figure 5) gets caught between the V-belt and the clutch. Always use safety gloves. CLUTCH PULLEY Figure 7. V-Belt Tension VIBRATOR PULLEY 3.
MVC-88GE/GEW PLATE COMPACTOR — OPERATION CAUTION - Read Instructions 3. Place the choke lever (Figure 11) in the "CLOSED " position if starting a cold engine. DO NOT attempt to operate the equipment until the Safety, General Information and Inspection sections of this manual have been read and thoroughly understood. This section is intended to assist the operator with the initial start-up. It is extremely important that this section be read carefully before attempting to use the equipment in the field.
MVC-88GE/GEW PLATE COMPACTOR — OPERATION 6. Grasp the starter grip (Figure 14) and slowly pull it out. The resistance becomes the hardest at a certain position, corresponding to the compression point. Pull the starter grip briskly and smoothly for starting. Stopping The Engine Normal Shutdown 1. Move the throttle lever to the IDLE position (Figure 17) and run the engine for three minutes at low speed. Figure 14. Starter Grip 7.
MVC-88GE/GEW PLATE COMPACTOR — MAINTENANCE CAUTI CAUTION CAUTI CAUTION Inspection and other services should always be carried out on hard and level ground with the engine shutdown. Inspection and Maintenance Service Tables. 1. To make sure your plate compactor is always in good working condition before using, carry out the maintenance inspection in accordance with Tables 4 through 6. These inspection intervals are for operation under normal conditions.
MVC-88GE/GEW PLATE COMPACTOR — MAINTENANCE TABLE 5. MACHINE INSPECTION Item ENGINE OIL 1. Drain the engine oil when the oil is warm as shown in Figure 20. Hours of Operation Star ting check Every 8 hours (every day) 2. Remove the oil drain bolt and sealing washer and allow the oil to drain into a suitable container. Loose or lost screws Every 8 hours (every day) Damage of any par t Every 8 hours (every day) 3. Replace engine oil with recommended type oil as listed in Table 3.
MVC-88GE/GEW— MAINTENANCE CHANGING VIBRATOR OIL 1. When changing the vibrator oil, remove the drain plug located at the bottom-right of the vibrator (Figure 8), and simply tip the compactor to drain the oil. Note that the oil will drain more easily while it is hot. Remember to use only 10W-30 motor oil when replacing vibrator oil. CAUTI CAUTION NEVER attempt to check the V-belt with the engine running. Severe injury can occur if your hand (Figure 5) gets caught between the V-belt and the clutch.
MVC-88GE/GEW— PREPARATION FOR LONG -TERM STORAGE Plate Compactor Storage For storage of the plate compactor for over 30 days, the following is required: ■ Drain the fuel tank completely or add STA-BIL to the fuel. ■ Run the engine until the fuel is completely consumed. ■ Completely drain the oil from the engine crankcase and follow procedures described in the ROBIN engine Owner's Manual for engine storage. ■ Completely drain the compactor's hydraulic oil from the vibrating case.
MVC-88GE/GEW—TROUBLESHOOTING (ENGINE) Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, please take remedial action following the diagnosis based on the Engine , and Compactor Troubleshooting (Tables 7, and 8) information shown below and on the proceeding pages. If the problem cannot be remedied, please leave the unit just as it is and consult or company's service department. TABLE 7.
MVC-88GE/GEW—TROUBLESHOOTING (ENGINE COMPACTOR) TABLE 7. ENGINE TROUBLESHOOTING (CONTINUED) SYMPTOM "Weak in power" compression is proper and does not misfire. POSSIBLE CAUSE SOLUTION Air cleaner not clean? Clean or replace air cleaner Improper level in carburetor? Check float adjustment, re-build carbureator. Defective Spark plug? Clean or replace spark plug. Defective Spark plug? "Weak in power" compression is proper but misfires. Engine overheats. Rotational speed fluctuates.
MVC-88GE/GEW — EXPLANATION OF CODE IN REMARKS COLUMN The following section explains the different symbols and remarks used in the Parts section of this manual. Use the help numbers found on the back page of the manual if there are any questions. NOTICE The contents and part numbers listed in the parts section are subject to change without notice. Multiquip does not guarantee the availability of the parts listed. SAMPLE PARTS LIST NO. 1 2% 2% 3 4 PART NO. PART NAME QTY. REMARKS 12345 BOLT..................
MVC-88GE/GEW — SUGGESTED SPARE PARTS MVC-88GE/GEW 1 TO 5 UNITS WITH ROBIN EX170D40050 ENGINE 1 to 5 Units Qty. P/N Description 3 ......... 070100332 ....... V-BELT 5 ......... 0650140150 ..... SPARK PLUG 1 ......... 2825011118 ..... ROPE, RECOIL STARTER 5 ......... 2773261107 ..... ELEMENT, CLEANER 1 ......... 0430440050 ..... CAP, FUEL TANK 1 ......... 0641360010 ..... FUEL FILTER, FUEL TANK 4 ......... 939010140 ....... SHOCK ABSORBER MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW— NAME PLATE AND DECALS NAME PLATE AND DECALS CAUTION 1 READ 0WNER’S MANUAL NPA 629 J 2 11 NPA-333 NAMEPLATE 10 3 9 NPA-845 J 8 SAE 10W-30 MOTOR OIL NPA-195 J CAUTION V BELT RPF-3330 NPA-835 J P/N 920106460 7 Fill up the sumps with oil before starting. Engine : Automobile engine oil SAE 10~30 Vibrator: Automobile engine oil SAE 10~30 Warm up the engine at idle speed for 3-5 minutes. NPA-306 J 4 l 5 6 PAGE 28 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW— NAME PLATE AND DECALS NAME PLATE AND DECALS NO PART NO PART NAME QTY. REMARKS 1 920206290 DECAL, READ OWNERS MANUAL ....... 1 ........ NPA-629 2 920203290 DECAL, CAUTION ................................. 1 ........ NPA-329 3 920208450 DECAL, LIFTING ................................... 1 ........ NPA-845 4 920203060 DECAL, CAUTION (START ENG/VIBR) . 1 ........ NPA-306 5 920208350 DECAL, V- BELT RPF-3330 ................... 1 ........ NPA-835 6 920201580 DECAL, MQ LOGO ..........................
MVC-88GE/GEW— BODY ASSY. VIBRATING PLATE ASSY. l PAGE 30 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW— BODY ASSY. BODY NO 21 23 24 25 31 32 33 35 36 37 38 39 40 41 42 43 45 46 47 48 49 51 52 53 54 55 56 57 91 92 93 94 95 96 97 101 102 103 ASSY.
MVC-88GE/GEW— VIBRATOR ASSY. VIBRATOR ASSY. l PAGE 32 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW— VIBRATOR ASSY. VIBRATOR ASSY. NO PART NO A 416910030 61# 416115990 62# 953400270 63# 953405260 64 001221635 65 030216400 66 031116260 68# 416338890 69# 040306211 70# 416338900 71# 416338910 72# 416338920 73# 060403060 74# 050101000 75# 001220825 76# 030208200 78# 416452720 79# 951405240 80# 952404250 81# 001221025 82# 030210250 PART NAME QTY. REMARKS VIBRATOR ASSY .................................. 1 ...........
MVC-88GE/GEW— SPRINKLER ASSY. (OPTION) SPRINKLER ASSY. (OPTION) l PAGE 34 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW— SPRINKLER ASSY. (OPTION) SPRINKLER ASSY. (OPTION) NO 111 111A * 112 * 113 * 114 * 115 * 116 * 117 * 118 * 119 * 120 * 121 # * 122 # * 123 # * 124 # * 125 # * PART NO 4169100109 416910010 033910050 953406390 954403241 416338930 416338940 416452750 001740825 416453780 416452790 954300340 001241030 033910010 022910180 416453800 PART NAME QTY. REMARKS WATER TANK ASSY. .................... 1 ............... INCLUDES ITEMS W/ * WATER TANK (W/CAP ONLY) ...... 1 ...............
MVC-88GE/GEW— TRANSPORT WHEEL ASSY. (OPTION) TRANSPORT WHEEL ASSY. (OPTION ) l PAGE 36 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
MVC-88GE/GEW— TRANSPORT WHEEL ASSY. (OPTION) TRANSPORT WHEEL ASSY. (OPTION ) NO 1 2 3 4 5 6 PART NO 416116160 959404310 031120320 025203030 416454150 025403025 PART NAME WHEEL SHAFT WHEEL 150X42 WASHER, FLAT M20 SPLIT COTTER PIN 3X30 ROLLER SPRING PIN 3X25 QTY. 1 2 2 2 2 3 REMARKS MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — AIR CLEANER ASSY. AIR CLEANER ASSY. l PAGE 38 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — AIR CLEANER ASSY. AIR CLEANER ASSY. NO PART NO 510 2773261500 200 2773263008 * 2773261008 210 * 2773260408 220 * 2773264008 250 * 2773260908 260 * 2773274108 270 * 2773274008 272 * 2773261107 520 * 0023806000 570 580 0110060050 850 0851080000 PART NAME QTY. REMARKS AIR CLEANER ASSY. ............................... 1 .................
EX-170D40050 — CAMSHAFT ASSY. CAMSHAFT ASSY. l PAGE 40 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — CAMSHAFT ASSY. CAMSHAFT ASSY. NO PART NO 10 2773160101 25 2773510103 27 0240060010 34% 2773860103 2773640103 35% 37% 2773650103 2773870103 38% 150 2773560101 160 2773691103 163 2773710103 166 2773690203 170 2773691313 PART NAME QTY. REMARKS CAMSHAFT .............................................. 1 .................
EX-170D40050 — CARBURETOR ASSY. CARBURETOR ASSY. l PAGE 42 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — CARBURETOR ASSY. CARBURETOR ASSY.
EX-170D40050 — CRANKCASE ASSY. CRANKCASE ASSY. l PAGE 44 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — CRANKCASE ASSY. CRANKCASE ASSY. NO PART NO 10 2771010141 30 * 0440250200 0600280021 40 * 50 * 2771501103 75 * 0440060020 80 0401140030 90$ 0211140020 210 2771100131 220% 0440250210 230% 0600250140 250 2774500421 260 2634190103 270 2776360113 275 2776500103 280$ 0213160020 281 0213160020 300 0010408350 700 2771501103 960 2779900107 PART NAME QTY. REMARKS CRANKCASE CP, W/OIL SENSOR ............. 1 ........
EX-170D40050 — CRANKSHAFT/PISTON ASSY. CRANKSHAFT/PISTON ASSY. l PAGE 46 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — CRANKSHAFT/PISTON ASSY. CRANKSHAFT/PISTON ASSY. NO PART NO PART NAME QTY. REMARKS 10 2772020111 CRANKSHAFT 1 50 0180140020 FLANGE NUT 1 70 0323030010 WOODRUFF KEY 1 80 0053005301 KEY 1 90 0200080050 WASHER 1 100 0011308200 BOLT & WASHER ASSY. 1 310 2772250110 CONNECTING ROD ASSY. ...................... 1 ................. INCLUDES ITEMS W/ * 320 2772300103 CONNECTING ROD BOLT 2 * 350 2772330103 PISTON PIN 1 360 2772340103 PISTON STD. 1 360 2772340303 PISTON, 0.25 O.S.
EX-170D40050 — CYLINDER HEAD ASSY. CYLINDER ASSY. l PAGE 48 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — CYLINDER HEAD ASSY. CYLINDER ASSY. NO PART NO 20# 2371420203 26# 2771601001 30 2793360103 40 2693370103 60# 0105080250 70# 0105060351 80 2773340113 90 2773350113 95 13210KA031 200 2773500123 220 2773610100 225 2773610200 230+ 0149050010 231$ 0149050010 240+ 0170050020 241$ 0170050020 290 0110060020 610 2771300101 620 2771500113 630 0110080240 631 0010408350 680 2771550101 690 2771600103 710 0110060020 PART NAME QTY.
EX-170D40050 — FUEL TANK ASSY. FUEL TANK ASSY. l PAGE 50 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — FUEL TANK ASSY. FUEL TANK ASSY. NO PART NO 10 2776010201 20 0732005180 23 2779510103 30 0430440050 40 0641360010 48 0505120020 60 0023806000 63 0110060130 80 0851960000 90 0561100030 PART NAME FUEL TANK LABEL, WARNING LABEL, MODEL FUEL TANK, CAP FUEL FILTER UNION FLANGE, NUT FLANGE, BOLT RUBBER PIPE, 6DX11D HOSE CLAMP, 10DX8BX1T QTY. 1 1 1 1 1 1 2 1 1 2 REMARKS MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — GOVERNOR ASSY. GOVERNOR ASSY. l PAGE 52 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — GOVERNOR ASSY. GOVERNOR ASSY.
EX-170D40050 — IGNITION COIL/FLYWHEEL ASSY. ELECTRIC DEVICE ASSY. l PAGE 54 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — IGNITION COIL/FLYWHEEL ASSY. ELECTRIC DEVICE ASSY. NO PART NO 10 2777923001 11 2777943011 30 0011406250 50 2777310101 60 X660000361 70 0150040090 100 0650140150 110 0655000270 PART NAME FLYWHEEL IGNITION COIL BOLT & WASHER WIRE 1 STOP SWITCH ASSY., ON-OFF TAPPING SCREW SPARK PLUG SPARK PLUG CAP QTY. 1 1 2 1 1 2 1 1 REMARKS MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — MUFFLER ASSY. MUFFLER ASSY. l PAGE 56 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — MUFFLER ASSY. MUFFLER ASSY. NO PART NO 310 2773010111 320 2773420111 340 2773520103 350 9802008280 360 0152060090 361 0110060010 365 0110080150 440 2773700101 445 0150040060 PART NAME MUFFLER MUFFLER COVER GASKET, MUFFLER FLANGE, NUT TAPPING BOLT FLANGE BOLT FLANGE BOLT DEFLECTOR TAPPING SCREW QTY. 1 1 1 2 2 1 1 1 2 REMARKS MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — RECOIL STARTER ASSY. COOLING AND STARTING ASSY. l PAGE 58 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV.
EX-170D40050 — RECOIL STARTER ASSY. COOLING AND STARTING ASSY. NO PART NO PART NAME QTY. REMARKS 10 2775120201 BLOWER, HOUSING CP 1 20 0732005140 LABEL, TRADEMARK 1 40 0110060030 FLANGE, BOLT 4 60 2775271111 BAFFLE, CASE 1 1 61 2775270203 BAFFLE, HEAD 2 1 80 0010406160 FLANGE, BOLT 1 81 0110060020 FLANGE, BOLT 1 210 2695020130 RECOIL STARTER ASSY. ...................... 1 ....................
TERMS AND CONDITIONS OF SALE — PARTS PAYMENT TERMS 5. Parts must be in new and resalable condition, in the original Multiquip package (if any), and with Multiquip part numbers clearly marked. 6. The following items are not returnable: Multiquip reserves the right to quote and sell direct to Government agencies, and to Original Equipment Manufacturer accounts who use our products as integral parts of their own products. a. SPECIAL EXPEDITING SERVICE Terms of payment for parts are net 30 days.
