Tip: A place to set down the coffee
machine at the level of the installation
recess is helpful. This makes it easier
for you to install the unit's electrical and
water connections.
^ Unscrew the four feet on the
underside of the unit by about 1/16"
(2 mm) using the larger Allen wrench.
The feet can be unscrewed by up to
3/8" (10 mm).
^ Connect the unit to the water supply
(see "Plumbing").
^
Connect the unit to the electrical
supply.
^
Insert the coffee machine all the way
into the installation recess.
When inserting the unit into the
recess, make sure the electrical and
water supply connections are not
damaged.
^
Check if the coffee machine is
centered and straight in the
installation recess. If not, align the
unit using the four feet.
The coffee machine is delivered with
four M5 Allen head screws that you can
use to align and fasten the unit in the
installation recess.
^
Open the door and partially tighten
the screws.
^ Align the unit by carefully adjusting
the lower Allen head screws until the
unit is centered in the installation
recess.
^ To secure the unit in the cabinet,
tighten the upper Allen head screws
by hand.
