Ventilation
When installing the coffee machine,
make sure that the back of the unit is
sufficiently ventilated so that steam and
hot air can freely escape.
The ventilation openings in the
surrounding cabinets and the space
below the ceiling must be at least
78 3/4"² (200 cm²).
Otherwise condensation can form,
causing damage to the coffee machine
or the surrounding cabinets.
Installation
Make sure that power is not
supplied to the appliance during
installation or removal of the unit.
When built into cabinetry, only use
the coffee machine in ambient
temperatures between +50°F/10°C
and +100°F/38 °C.
You will need two Allen wrenches
size 3 and 5 for the installation.
To align the unit door flush with the
kitchen cabinetry, there must be a
sealing strip around the installation
recess; otherwise, a sealing strip must
be put in place around the unit.
^
If there is no sealing strip around the
installation recess, stick the Miele
sealing strip onto the unit from the
back before putting it into the recess.
The sealing strip is available from
Miele.
Installation
